Johnson Controls tyco TY-FRB Series Manual page 8

TFP296
Page 8 of 8
376 5.6K EC HSW
396 8.0K EC HSW
SERIES TY-FRB EXTENDED COVERAGE HORIZONTAL SIDEWALL SPRINKLERS
Limited
Warranty
For warrany terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name and Part Number
(P/N).
Sprinkler Assembly with
NPT Thread Connections
Specify: Series TY-FRB, (specify SIN),
Extended Coverage Horizontal Side-
wall Sprinkler, K=(specify), (specify)
temperature rating, (specify) finish, P/N
(specify from Table E)
Recessed Escutcheon
Specify: Style (10, 20, 30, or 40)
Recessed Escutcheon with (specify*)
finish, P/N (specify*)
* Refer to Technical Data Sheet TFP770
Sprinkler Wrench
Specify: W-Type 6 Sprinkler Wrench,
P/N 56-000-6-387
Specify: W-Type 7 Sprinkler Wrench,
P/N 56-850-4-001
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone +1-215-362-0700
© 2018 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association;
TEFLON is a registered trademark of DuPont
57 - XXX - X - XXX
1
3
SIN
TY3332
4
TY4332
5
9
TABLE E
PART NUMBER SELECTION
SPRINKLER FINISH
NATURAL BRASS
PURE WHITE (RAL9010)
POLYESTER
SIGNAL WHITE (RAL9003)
POLYESTER
JET BLACK (RAL9005)
POLYESTER
CHROME PLATED
TEMPERATURE
RATING
135 135°F (57°C)
155 155°F (68°C)
175 175°F (79°C)
