MOUNTING
SURFACE
CLOSURE
SERIES
TY-FRB EC
MOUNTING
PLATE
1-1/4" (31,8 mm)
3/4" (19,1 mm)
FIGURE 5
SERIES TY-FRB RECESSED EC SIDEWALL
SPRINKLER ASSEMBLY WITH TWO-PIECE
3/4 INCH TOTAL ADJUSTMENT
STYLE 10 RECESSED ESCUTCHEON
5.6 K-FACOTR, 1/2 INCH NPT
MOUNTING
SURFACE
CLOSURE
SERIES
TY-FRB EC
MOUNTING
PLATE
1-1/4" (31,8 mm)
3/4" (19,1 mm)
FIGURE 7
SERIES TY-FRB RECESSED EC SIDEWALL
SPRINKLER ASSEMBLY WITH TWO-PIECE
3/4 INCH TOTAL ADJUSTMENT
STYLE 40 RECESSED ESCUTCHEON
8.0 K-FACTOR, 3/4 INCH NPT
5/8±1/4"
(15,9±6,4 mm)
FACE OF
SPRINKLER
FITTING
2-7/8" DIA.
(73,0 mm)
2-1/4" DIA.
(57,2 mm)
1/8"
(3,2 mm)
3/4" (19,1 mm)
1/4" (6,4 mm)
5/8±1/4"
(15,9±6,4 mm)
FACE OF
SPRINKLER
FITTING
2-7/8" DIA.
(73,0 mm)
2-1/4" DIA.
(57,2 mm)
1/8"
(3,2 mm)
3/4" (19,1 mm)
1/4" (6,4 mm)
MOUNTING
SURFACE
CLOSURE
SERIES
TY-FRB EC
MOUNTING
PLATE
1-1/4" (31,8 mm)
1" (25,4 mm)
FIGURE 6
SERIES TY-FRB RECESSED EC SIDEWALL
SPRINKLER ASSEMBLY WITH TWO-PIECE
1/2 INCH TOTAL ADJUSTMENT
STYLE 20 RECESSED ESCUTCHEON
5.6 K-FACTOR, 1/2 INCH NPT
MOUNTING
SURFACE
CLOSURE
SERIES
TY-FRB EC
MOUNTING
PLATE
1-1/4" (31,8 mm)
1" (25,4 mm)
FIGURE 8
SERIES TY-FRB RECESSED EC SIDEWALL
SPRINKLER ASSEMBLY WITH TWO-PIECE
1/2 INCH TOTAL ADJUSTMENT
STYLE 30 RECESSED ESCUTCHEON
8.0 K-FACTOR, 3/4 INCH NPT
TFP296
Page 7 of 8
1/2±1/8"
(12,7±3,2 mm)
FACE OF
SPRINKLER
FITTING
2-7/8" DIA.
(73,0 mm)
2-1/4" DIA.
(57,2 mm)
1/8"
(3,2 mm)
1/2" (12,7 mm)
1/4" (6,4 mm)
1/2±1/8"
(12,7±3,2 mm)
FACE OF
SPRINKLER
FITTING
2-7/8" DIA.
(73,0 mm)
2-1/4" DIA.
(57,2 mm)
1/8"
(3,2 mm)
1/2" (12,7 mm)
1/4" (6,4 mm)
