5.6K EXTENDED COVERAGE HORIZONTAL SIDEWALL SPRINKLER (TY3332)
Coverage
Response
Area (1)
Rating
ft x ft (m x m)
Quick 16 x 16 (4,9 x 4,9)
Quick 16 x 18 (4,9 x 5,5)
Quick 16 x 20 (4.9 x 6,1)
Standard 16 x 16 (4,9 x 4,9)
Standard 16 x 20 (4,9 x 6,1)
Standard 16 x 22 (4,9 x 6,7)
8.0K EXTENDED COVERAGE HORIZONTAL SIDEWALL SPRINKLER (TY4332)
Coverage
Response
Area (1)
Rating
ft x ft (m x m)
Quick 16 x 16 (4,9 x 4,9)
Quick 16 x 18 (4,9 x 5,5)
Quick 16 x 20 (4.9 x 6,1)
Quick 16 x 22 (4,9 x 6,7)
Quick 16 x 24 (4,9 x 6,7)
Standard 16 x 16 (4,9 x 4,9)
Standard 16 x 18 (4,9 x 5,5)
Standard 16 x 20 (4.9 x 6,1)
Standard 16 x 22 (4,9 x 6,7)
Standard 16 x 24 (4,9 x 6,7)
Notes:
1. Backwall (where sprinkler is located) by sidewall (length of throw)
2. Requirement is based on maintaining both minimum flow and minimum residual pressure.
3. The centerline of the sprinkler waterway is located 7/16 in. (11,1 mm) below the deflector (Ref. Figures 1 and 2).
4. Minimum spacing is for lateral distance between sprinklers located along a single wall, otherwise adjacent sprinklers (i.e., sidewall sprinklers on an adjacent wall, on an oppo-
site wall, or pendent sprinklers) must be located outside of the maximum listed protection area of the extended coverage sidewall sprinkler being utilized.
Minimum Minimum
, Flow (2) , Pressure
gpm (lpm) psi (bar)
26 (98) 22 (1,51)
30 (114) 29 (2,00)
33 (125) 35 (2,41)
26 (98) 22 (1,51)
30 (114) 29 (2,00)
33 (125) 35 (2,41)
Minimum Minimum
, Flow (2) , Pressure
gpm (lpm) psi (bar)
32 (121) 16 (1,10)
36 (136) 20 (1,38)
40 (151) 25 (1,72)
44 (167) 30 (2,06)
48 (182) 36 (2,48)
32 (121) 16 (1,10)
36 (136) 20 (1,38)
40 (151) 25 (1,72)
44 (167) 30 (2,06)
48 (182) 36 (2,48)
FM COVERAGE AND FLOW RATE CRITERIA
Deflector-to-Ceiling
(2) , Distance (3) ,
Inches (mm)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300))
Deflector-to-Ceiling
(2) , Distance (3) ,
Inches (mm)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300)
4 to 12 (100 to 300))
4 to 12 (100 to 300)
4 to 12 (100 to 300))
4 to 12 (100 to 300)
4 to 12 (100 to 300)
TABLE D
TFP296
Page 5 of 8
Sprinkler Minimum
Temperature Spacing
Rating, °F ft (m)
135, 155 10 (3,1)
135, 155 10 (3,1)
135, 155 10 (3,1)
175 10 (3,1)
175 10 (3,1)
175 10 (3,1)
Sprinkler Minimum
Temperature Spacing
Rating, °F ft (m)
135, 155 10 (3,1)
135, 155 10 (3,1)
135, 155 10 (3,1)
135, 155 10 (3,1)
135, 155 10 (3,1)
175 10 (3,1)
175 10 (3,1)
175 10 (3,1)
175 10 (3,1)
175 10 (3,1)
(4) ,
(4) ,
