Montageanleitung / Installation Guide
5. HAUPTKOMPONENTE & ANSCHLUSS / MAIN COMPONENTS & CONNECTION
GERMAN - DE
10. Pumpe Wilo Yonos 15/6
19. Endstück mit manueller Entlüftung
25. Danfoss ECL 110
29. Stellantrieb AMV 140
30. Danfoss Ventil VS2, kVs 1,0
52. Zonenventil Danfoss VMT/TWA-V
54. Sicherheitsthermostat
58. Verteiler mit 7 Anschlüssen mit Durchflussmesser
90. Danfoss FH-WC Regler
90A Thermo-Motor Danfoss TWA-A NC 230 V
ENGLISH - GB
10 Pump Wilo Yonos 15/6
19. Manual air vent and drain valve
25. Manifold w. 7 connecting pieces, with flow meter
29. Danfoss FH-WC controller
30. Thermo-actuator Danfoss TWA-ANC 230 V
52 Zone valve Danfoss VMT/TWA-V
54.
Safety thermostat
58. Manifold w. 7 connecting pieces, with flow meter
90.
Danfoss FH-WC controller
90A Thermo-actuator Danfoss TWA-A NC 230 V
GERMAN - DE
ENGLISH - GB
Optionen:
Kugelhahn-Set incl. Montageschiene - Kode Nr. 145H3938
Option:
Mounting rail set with 76 mm ball valves - Code No. 145H3938
VI.LZ.C1.5B
Edelstahl Verteilersysteme / Stainless steel distribution units SGTZC
19
19
© Danfoss | Produced by Danfoss Redan A/S | 2017.11 | 9
90 52
25
58
54
58
90A
29
10
