The meaning of the columns in the "SDO Write" are:
In the field "Device ID" the ID of the device to
write is defined;
In the field "Index" the address for the SDO to
write is defined;
In the field "SubIndex" the second address for
the SDO to write is defined;
In the field "N Byte" the dimension of the SDO
to write is defined (it can be 1, 2, or 4);
In the field "Poll Time" the time to make the
request is defined;
If the field "On Change" is checked, the
converter sends the writing request when the
data from OPC UA side changes;
In the field "Address Byte1" the byte of the internal memory array where taking the 1
In the field "Address Byte2" the byte of the internal memory array where taking the 2
Byte is 2 or 4);
In the field "Address Byte3" the byte of the internal memory array where taking the 3
Byte is 4);
In the field "Address Byte4
Byte is 4);
In the field "Mnemonic" the description for the SDO is defined.
ADFweb.com Srl – IT31010 – Mareno – Treviso
Figure 6b: "Set SDO Client Access – SDO Write" window
the byte of the internal memory array where taking the 4
User Manual OPC UA Server / CANopen
Document code: MN67B34_ENG Revision 1.000
st
byte of the SDO write is defined;
nd
byte of the SDO write is defined (only if N
rd
byte of the SDO write is defined (only if N
th
byte of the SDO write is defined (only if N
