Technical Specifications
CR2450
Power supply
Loxone Air:
Interface
868MHz (SRD Band Europe),
4 channels available
915MHz (ISM Band Region 2),
10 channels available
max. Power 3.16mW
Ambient temperature
-20 ... 60°C / -4 ... 140°F
Humidity
max. 95% r.H. (non condensing)
Touch points
5 touch points, capacitive
touch detection
Click feedback
Yes
Temperature detection range
-40 ... 125°C / -40 ... 257°F
+/- 0.5°C / 0.9°F
Humidity detection range
0 ... 100% r.H. +/- 2%
(non condensing)
Safety rating
IP40
Dimensions
80x80x10mm /
3.15x3.15x0.4" (LxWxH)
Maintenance & Cleaning
This device is free of main-
tenance and may only be
cleaned with a dry cloth.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Touch
Air
Part No: 100155 (White)
Part No: 100180 (Anthracite)
Advertisement
Table of Contents
Related Manuals for LOXONE Touch Air
Summary of Contents for LOXONE Touch Air
- Page 1 Humidity detection range 0 ... 100% r.H. +/- 2% (non condensing) Safety rating IP40 Dimensions 80x80x10mm / Loxone Electronics GmbH 3.15x3.15x0.4” (LxWxH) Smart Home 1 Maintenance & Cleaning This device is free of main- 4154 Kollerschlag Part No: 100155 (White)
- Page 2 About the product The Loxone Touch has five touch zones, which can be configured according to your needs. The large central touch zone is ideal for controlling lighting, whilst the corner zones are handy for controlling music and blinds. Features •...
