Technical Specifications
Power supply
5 ... 30VDC or
2x 1.5V AA batteries
Power consumption
typ. 170mW, max. 1.2W
Power loss
max. 1.2W
Interface
Loxone Air:
868MHz (SRD Band Europe),
4 channels available
915MHz (ISM Band Region 2),
10 channels available
max. Power 3.16mW
Ambient temperature
-20 ... 55°C / -4 ... 131°F
Humidity
max. 80% r.H. (non condensing)
Push force
min. 70N
Stroke length
5.3mm / 0.21"
Temperature detection range
-40 ... 125°C / -40 ... 257°F;
+/- 0.5°C / 0.9°F
Safety rating
IP 20
Dimensions
49x78.8mm / 1.93x3.10" (DxH)
with valve adapter
49x72.3mm / 1.93x2.85" (DxH)
without valve adapter
This device is free of main-
Maintenance & Cleaning
tenance and may only be
cleaned with a dry cloth.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Valve
Actuator
Air
Part No: 100163
