Important Safety Information

Installing Warning Signs and Pedestrian Gates

Warning signs alert people of automatic gate operation and are required when installing Mighty Mule Automatic
Gate Operators. A minimum of two WARNING SIGNS must be installed in the area of the gate. Each sign is to be
visible by persons located on the side of the gate on which the placard is installed.
The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a
separate access opening. The pedestrian access opening shall be designed to promote pedestrian usage. Locate
the gate such that persons will not come in contact with the vehicular gate during the entire path of travel of the
vehicular gate.
We recommend using the NSC Pedestrian Gate Lock (Call the NSC Sales Department at 800-543-4283) for
controlled access.
Pedestrian Gate Lock
(recommended, not included
)
7 foot
Pedestrian Gate Warning Sign
minimum
Vehicular Gate
Warning Signs
The gate operator is provided with 2 safety warning signs.
The signs MUST be installed on the front and back of the
gate where they will be visible in the area of the gate.
Permanently secure each warning sign to the gate.
Immediately replace a damaged or missing warning sign.
viii
HD272 Installation Instructions
Warning Sign
Vehicular Gate
!
Important Safety Information

Required Safety Precautions for Gates

These warning labels should be found at the locations specified below. If any of them are missing, immediately
contact NSC for replacements.
WARNING
AVERTISSEMENT
Moving gate can cause injury or death!
1. KEEP CLEAR! Gate may move at any time.
2. Read all SAFETY INSTRUCTIONS in the user's manual.
3. Do not allow children to operate gate or play in gate area.
4. This gate is for vehicles only. Pedestrians must use separate entrance.
La barrière en mouvement peut provoquer des
blessures graves ou la mort!
1. TENEZ-VOUS LOIN! La barrière peut se déplacer à tout moment.
2. Lisez toutes les instructions de sécurité dans le manuel de l'utilisateur.
3. Ne laissez pas les enfants utiliser la barrière ou jouer à proximité de la barrière.
4. Cette barrière est uniquement réservée aux véhicules. Les piétons doivent
utiliser une autre entrée.
Labels (1) installed on the front of control box
Control arm label (2) installed on operator arm
GEN7 SERIES – DC Swing Gate Operator
P/N MM571W
Conforms to UL STD 325 • Certified to CSA STD C22.2 No.247
Maximum Gate: 300 lb. (136 kg); 12 ft. (3.65 m)
Voltage: 12 Vdc; Frequency: 0 Hz; Power: 25 W
E472888
Class I Vehicular Gate
Product identi cation label (1) installed on the side of the Control box.
10019674A
mightymule.com
MM571W
S/N: YYYYMMDDx0000
Nortek Security & Control – Carlsbad, CA USA 10019665A
HD272 Installation Instructions
