O.E.M. WHEELS & TIRES CAN BE REINSTALLED WITH THIS KIT.
FABTECH RECOMMEND'S A 12"x7" WHEEL WITH A 5+2 OFFSET WITH A 26"x 9"x 12"TIRE IN
FRONT AND A 12" x 10" WHEEL WITH A 5 + 5 OFFSET WITH A 26"x 12"x12" TIRE IN THE REAR
www.fabtechmotorsports.com
Rhino Long Travel System
FTR10079, FTR10013, FTR10080

TOOL LIST:

o Assorted Metric & Standard Wrenches
o Torque Wrench
o Floor Jack
o Jack Stands
o Air Saw
o Die Grinder w/ sanding discs
o CV Boot Clamp Crimping Tool
(may require minor trimming)
2008 Yamaha Rhino
FT95024 Hardware Kit -
Qu
a Description
2 3/8"-24 x 3 1/4" Bolt
2 3/8"-24 C-Lock Nut
2 3/8" USS Flat Washers
2 3/8" SAE Flat Washers
2 1/2"-20 Jam Nut
2 10mm x 1.50 x 60mm Bolt
2 10mm x 1.50 C-Lock Nut
4 10mm SAE Flat Washer
2 9/16-18 x 3" Bolt
2 9/16"-18 C-Lock Nut
2 9/16" SAE Flat Washer
2 9/16"-18 x 3 1/2" Bolt
2 9/16"-18 C-Lock Nut
4 1/4"-20 x 3/4" Bolt
4 1/4"-20 C-Lock Nut
8 1/4" SAE Flat Washer
4 7/16 SAE Flat Washers
4 5/8" I.D. Adel/Line Clamp
Location
Outer Tie Rod End
Frt Lwr Shock Mnt
Upr Ball Joint (Heim Joint)
Lwr Ball Joint (Uni-Ball)
Brake Line Tabs
Rr Lwr Shock Bolt
