Fabtech FTR10079 Manual page 2

www.fabtechmotorsports.com
Rhino Long Travel System
FTR10079, FTR10013, FTR10080
FTR10079 Box 1 (Arms)
Qu
a Part # Description
FT95006G
1 R Drv Rr Upper Control Arm
FT95008G
1 R Pass. Rr Upper Control Arm
1 FT95024 Hardware Kit
FT95067G
1 R Drv Frt Upper Control Arm w/heim
FT95068G
1 R Drv Frt Lower Control Arm w/uni
FT95069G
1 R Pass. Frt Upper Ctrl Arm w/heim
FT95070G
1 R Pass. Frt Lower Cntrl Arm w/uni
FT95162G
1 R Drv Rr Lower Control Arm
FT95163G
1 R Pass. Rr Lower Control Arm
1 FT95234 Hdwr Sub-Assembly Kit
FTR10013 Box 2 (Shocks & Steering)
Qu
a Part # Description
1 FTR60138 Front Shock w/ Mounting Hardware
1 FTR60141 Rear Shock w/ Mounting Hardware
2 FT95015 Tie Rod End Extension
2 FT95023 1/2" x 1/2" Heim
2 FT95020 Mis-Alignment 1/2" Heim (Short)
2 FT95021 Steering Arm Hat w/mis-alignment
909-597-7800 Fax 909-597-7185
2008 Yamaha Rhino
FT95234 Hardware Sub-Assembly
Qu
a Part # Description
2500000505
12 2 1/4" SAE Flat Washer
2520000305
6 2 1/4"-20 Nylock Nut
2520100105
6 2 1/4"-20 x 1" Hex Cap Bolt
2 FTR10079i Instruction Sheet
34 FT95000 Control Arm Bushing Half
16 FT95001 Control Arm Sleeve
2 FT95010 Upper Ball Joint Hat
2 FT95019 Lower Ball Joint Hat
2 FT95027 7/8" Mis Alignments
4 FT95066 Mis-Alignment
2 FT95079 Lower Ball Joint Mis-Alignments
6 FTClamp Adel Clamp
2 FTLOCK Thread Locking Compound
2 FTLUBE Lube
FTR10080 Box 3 (Axles)
Qu
a Part # Description
Front Drv / Pass Long Travel
2 FT95165 Axle
1 FT95166 Rear Driver Long Travel Axle
Rear Passenger Long Travel
1 FT95167 Axle
1 FT95060 Boot Clamp Kit W/Snap Ring
4 FT95065 Grease Pack
1 FT95161 Rear Brake line
