- Page 1 UNIVERSAL WORK SURFACES USER GUIDE...
- Page 2 PRODUCT OVERVIEW User Guide This page was intentionally left blank.
-
Page 3: Warranty
TABLE OF CONTENTS User Guide TABLE OF CONTENTS Safety Information Installation Instructions WARRANTY CONTACT YOUR SALES REPRESENTATIVE FOR WARRANTY INFORMATION... -
Page 4: Important Safety Instructions
SAFETY INFORMATION User Guide SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS Save these instructions. WARNING: To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product. Do not change or replace components and accessories provided by the manufacturer. KEEP AWAY FROM CHILDREN This table system is not designed for use in homes or other areas accessible by small children. -
Page 5: Installation
INSTALLATION INSTRUCTIONS User Guide INSTALLATION INSTRUCTIONS The installation of the work surface to be made in accordance with this manual. Changes to the work surface or improper use may affect the safety, function, and life of your product. These instructions are intended to assist the installer with the most common product configurations. If your base requires the use of different hole locations, please disregard these locator holes and follow instructions provided with your product. - Page 6 INSTALLATION INSTRUCTIONS User Guide If your top support looks like this: FASTEN PRE-ASSEMBLED COLUMNS TO THE WORK SURFACE Use the corresponding locator holes to position. See Illustration A Be sure top supports are mounted 1.5" from edge of work surface. Max Rated Load (including table top): 250 lb.
- Page 7 INSTALLATION INSTRUCTIONS User Guide If your top support looks like this: FASTEN PRE-ASSEMBLED TABLE FRAME ONTO WORKSURFACE Use the corresponding locator holes to position. See Illustration B Locator holes fit to standard Full Length T&C Leg configurations. Max Rated Load (including table top): 225 lb. ILLUSTRATION B C-Leg T-Leg...
- Page 8 INSTALLATION INSTRUCTIONS User Guide If your top support looks like this: FASTEN TOP SUPPORTS TO THE TABLE TOP Use the corresponding locator holes to position. See Illustration C Be sure top supports are mounted 1.5" from edge of work surface. Max Rated Load (including table top): 200 lb.
- Page 9 USER GUIDE Rev B | 092520...
