- Page 1 OV1001 OV1001 HEIGHT ADJUSTABLE TABLE DISASSEMBLY GUIDE...
- Page 2 HEIGHT ADJUSTABLE TABLE A healthier work environment starts with the option to sit or stand throughout the day. The OV1001 table is the industry standard in height-adjustable products, and your first step towards improving the efficiency and well-being of your organization.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Disassembly Guide: OV1001 TABLE OF CONTENTS Parts Diagram Full Length Independent Adjustable L-Rail Three-Leg Disassembly Instructions 8-11 Customer Service Standards & Certifications This manual explains how this sit-stand desk is disassembled, used, and main- tained. All sit-stand tables are subjected to functional and quality tests before... -
Page 4: Parts Diagram
PARTS DIAGRAM Disassembly Guide: OV1001 OV1001 PARTS DIAGRAM FULL LENGTH For tables up to 84" PARTS/MATERIAL Qty/Package 1. J-Rail/Steel 2. Column/Steel, mixed materials 3. Top Support/Steel 4. Foot/Steel 5. M6x1.0 12mm Screw/Steel 6. Handswitch/Mixed plastic,metals E Control Box/Mixed plastic,metals E 8. -
Page 5: Independent
PARTS DIAGRAM Disassembly Guide: OV1001 INDEPENDENT For tables 60" or Less PARTS/MATERIAL Qty/Package 1. Column/Steel,mixed materials 2. Top Support/Steel 3. Foot/Steel 4. Control Box/Mixed plastic,metals E 5. Handswitch/Mixed plastic,metals E 6. Power Cord/Copper,mixed materials E M10x1.5 20mm Screw/Steel 8. M6x1.0 12mm Screw/Steel 9. -
Page 6: Adjustable L-Rail
PARTS DIAGRAM Disassembly Guide: OV1001 ADJUSTABLE L-RAIL For tables up to 84” PARTS/MATERIAL Qty/Package 1. Column/Steel,mixed materials 2. Top Support/Steel 3. Foot/Steel 4. Adjustable L-Rail/Steel 5. Control Box/Mixed plastic,metals E 6. Handswitch/Mixed plastic,metals E Power Cord/Copper,mixed materials E 8. M10x1.5 20mm Screw/Steel 9. -
Page 7: Three-Leg
PARTS DIAGRAM Disassembly Guide: OV1001 THREE-LEG PARTS/MATERIALS Qty/Package 1. Column/Steel,mixed materials 2. Top Support/Steel 3. Foot/Steel 4. J-Rail/Steel 5. Left Hand Adapter Bracket/Steel 6. Right Hand Adapter Bracket/Steel Third Leg Bracket/Steel 8. Control Box/Mixed plastic,metals E 9. Power Cord/Copper,mixed materials E 10. -
Page 8: Disassembly Instructions
The disassembly of the table frame to be made in accordance with this manual. Changes to the table frame or improper use may affect the safety, function, and life of your product. This manual is for all sit-stand tables from the OV1001 series. Due to different models or types, pictures may vary. - Page 9 DISASSEMBLY INSTRUCTIONS Disassembly Guide: OV1001 DISCONNECT THE HANDSWITCH (HS) CABLE FROM THE CONTROL BOX DISCONNECT THE SUPPLIED POWER CORD (AC) FROM THE CONTROL BOX DETACH ALL CABLES FROM THE TABLE FRAME OR THE UNDERSIDE OF THE TABLE TOP Detach cables in order to avoid any damage during operation.
- Page 10 DISASSEMBLY INSTRUCTIONS Disassembly Guide: OV1001 UNFASTEN THE TABLE FRAME FROM THE TABLE TOP FULL LENGTH INDEPENDENT ADJUSTABLE L-RAIL THREE-LEG Please make sure top supports are mounted 1.5" from edge of work surface. 10 | OV1001...
- Page 11 DISASSEMBLY INSTRUCTIONS Disassembly Guide: OV1001 DISASSEMBLE THE THIRD COLUMN FROM THE ADAPTER BRACKETS (FOR THIRD LEG ASSEMBLY ONLY) DISASSEMBLE THE FOOT TO THE COLUMN DISASSEMBLE THE COLUMN FROM THE J-RAIL DISASSEMBLE THE TOP SUPPORT FROM THE COLUMN OV1001 | 11...
-
Page 12: Customer Service
CUSTOMER SERVICE Disassembly Guide: OV1001 CUSTOMER SERVICE If you have any problems with PHONE: 1-616-738-6688 your table base, please contact FAX: 1-616-738-6682 our service department. STANDARDS & CERTIFICATIONS The drive system is tested according to the following standards: UL 962 Issued: 2014/11/07 Ed: 4 Household and Commercial Furnishings CSA C22.2#68... - Page 13 OV1001 DISASSEMBLY GUIDE Rev 081717...
