Page 1
OV1024 | Part No. 122524 OV1024 HEIGHT ADJUSTABLE TABLE USER GUIDE...
Page 2
PRODUCT OVERVIEW User Guide: OV1024 OV1024 HEIGHT ADJUSTABLE TABLE FEATURES • Complete height adjustable table • Easy-order with one part number • Lift capacity up to 150 lb. 2 | OV1024...
TABLE OF CONTENTS User Guide: OV1024 TABLE OF CONTENTS Parts Diagram Safety Information Assembly Instructions 7-10 Operation Troubleshooting Technical Data Warranty This manual explains how this sit-stand desk is assembled, used, and maintained. All sit-stand tables are subjected to functional and quality tests before leaving our facility.
PARTS DIAGRAM User Guide: OV1024 OV1024 PARTS DIAGRAM PARTS Qty/Package 1. Column 2. Handswitch 3. Control Box 4. Power Cord 5. #10 x ¾" Screw 6. 37mm Locking Caster Laminate Work Surface 8. Eight-Outlet Power Strip with Mounting Bracket (optional)
To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product. Do not change or replace components and accessories provided by OMT-Veyhl. KEEP AWAY FROM CHILDREN For indoor use only.
Page 6
SAFETY INFORMATION User Guide: OV1024 DO NOT OVERLOAD DESK To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability and lead to tip over.
The assembly of the table frame to be made in accordance with this manual. Changes to the table frame or improper use may affect the safety, function, and life of your product. This manual is for all sit-stand tables from the OV1024 series. ASSEMBLY OVERVIEW 1.
Page 8
ASSEMBLY INSTRUCTIONS User Guide: OV1024 ASSEMBLE THE COLUMNS TO THE WORK SURFACE Work surface is pre-drilled with mounting holes for columns. Align columns with pre-drilled mounting holes in work surface, and use the #10 x ¾" screws to fasten the top support onto the table top.
Page 9
ASSEMBLY INSTRUCTIONS User Guide: OV1024 FASTEN THE CONTROL BOX AND HANDSWITCH TO THE TABLE TOP Work surface is pre-drilled with mounting holes for control box and handswitch. Align control box and hand switch with pre-drilled mounting holes in work surface. Make sure the control box and handswitch are fastened so that all the cables will connect without being in tension.
Page 10
ASSEMBLY INSTRUCTIONS User Guide: OV1024 CONNECT THE SUPPLIED POWER CORD (AC) TO THE CONTROL BOX ATTACH ALL CABLES TO THE TABLE FRAME OR ON THE UNDERSIDE OF THE TABLE TOP Attach cables in order to avoid any damage during operation.
OPERATION INFORMATION User Guide: OV1024 OPERATION INFORMATION INITIALIZATION/RESET The desk must be initialized/reset after any of the following: - After assembly - After disconnection from the power supply - After any impact on the table top. To initialize/reset, move the table to the lowest position by pressing the DOWN button on the handswitch until the columns reach the lowest position.
TROUBLESHOOTING User Guide: OV1024 TROUBLESHOOTING UNIT ERROR CODE SOURCE SOLUTION No power supply Plug in the power cord or check the connection Table does not on the control box move No connection or a loose Verify the plug connections of the motor cable...
TECHNICAL DATA User Guide: OV1024 TECHNICAL DATA GENERAL CONTROL BOX Power supply 120 VAC ±10% / 60 Hz Standby power consumption, primarily <0.3 W Operating temperature 0-35°C Protection class IP 20 Maximum power output 240VA/24V TWO-COLUMN FRAME WITH CONTROL BOX Maximum lift capacity 150 lb (≈...
WARRANTY User Guide: OV1024 WARRANTY CONTACT YOUR SALES REPRESENTATIVE FOR WARRANTY INFORMATION End of life cycle: Once product is disassembled, all steel components can be recycled at your local metal collector. 14 | OV1024...
Page 15
OV1024 USER GUIDE Part No. 122524 RevA | 051320...
