- Page 1 OV1013 | Part No. 80161 OV1013 HEIGHT ADJUSTABLE TABLE USER GUIDE...
-
Page 2: Column
HEIGHT ADJUSTABLE TABLE A healthier work environment starts with the option to sit or stand throughout the day. Our OV1013 table is the industry standard in height-adjustable products, and the first step towards improving the efficiency and well-being of any organization. - Page 3 TABLE OF CONTENTS User Guide: OV1013 TABLE OF CONTENTS Parts Diagram Safety Information Assembly Instructions Operation 10-11 Troubleshooting 12-13 Customer Service Standards & Certifications This manual explains how this sit-stand desk is assembled, used, and maintained. All sit-stand tables are subjected to functional and quality tests before leaving our facility.
- Page 4 PARTS DIAGRAM User Guide: OV1013 OV1013 PARTS DIAGRAM FULL LENGTH For tables 48" - 72" PARTS Qty/Package 1. Column 2. Foot (24" or 30") 3. Support Rail 4. Top Support –Right Hand 5. Top Support –Left Hand 6. Wire Management Kit Glide 8.
-
Page 5: Safety Information
SAFETY INFORMATION User Guide: OV1013 SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS Save these instructions. DANGER To reduce the risk of electric shock: Always unplug this furnishing from the electrical outlet before cleaning. WARNING: To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product. -
Page 6: Safety Information
SAFETY INFORMATION User Guide: OV1013 DO NOT OVERLOAD DESK To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability and lead to tip over. -
Page 7: Assembly Instructions
The assembly of the table frame to be made in accordance with this manual. Changes to the table frame or improper use may affect the safety, function, and life of your product. This manual is for all sit-stand tables from the OV1013 series. ASSEMBLY OVERVIEW 1. -
Page 8: Support Rail
ASSEMBLY INSTRUCTIONS User Guide: OV1013 ASSEMBLE THE RAIL TO THE COLUMN Fit the support rail onto the column mounting plate using the provided M6 x 10mm flat head screws. NOTE: Insert screws to support rail from the inside of the rail. -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS User Guide: OV1013 FASTEN THE TABLE FRAME ONTO THE TABLE TOP Position columns on the table top. Drill 3/32" pilot holes using the #10 x 1" wood screws provided. NOTE: Reference Safety Information on page 5-6 before proceeding. -
Page 10: Operation
OPERATION INFORMATION User Guide: OV1013 OPERATION INFORMATION INITIALIZATION/RESET The desk may need to be initialized/reset after any of the following: - After assembly - After disconnection from the power supply - After any impact on the table top. To initialize/reset, you will need to move the table to the lowest position by holding the DOWN button of the handswitch until all columns reach the lowest position. -
Page 11: Operation
OPERATION INFORMATION User Guide: OV1013 PROGRAMMABLE HANDSWITCH OPERATION (continued) CHANGE THE HEIGHT UNIT (inches or centimeters) The height display of the handset can display either centimeters or inches. With the help of the S5-menus, the unit can be changed. If the display was originally set to centimeters, then after the procedure noted below it will change to inches or vice versa. -
Page 12: Troubleshooting
TROUBLESHOOTING User Guide: OV1013 TROUBLESHOOTING UNIT ERROR CODE SOURCE SOLUTION No power supply Plug in the power cord or check the connection Table does not on the control box move No connection or a loose Verify the plug connections of the motor cable... -
Page 13: Troubleshooting
TROUBLESHOOTING User Guide: OV1013 HANDSWITCH DISPLAY ERROR CODE SOURCE SOLUTION The control box monitors the duty cycle (time-controlled) and its max Wait until the “HOT” display goes out - the table is working properly again temperature. A value has been exceeded. -
Page 14: Customer Service
CUSTOMER SERVICE User Guide: OV1013 CUSTOMER SERVICE If you have any problems with PHONE: 1-616-738-6688 your table base, please contact FAX: 1-616-738-6682 our service department. 14 | OV1013... -
Page 15: Standards & Certifications
STANDARDS & CERTIFICATIONS User Guide: OV1013 STANDARDS & CERTIFICATIONS Meets 2014 BIFMA standards. WARRANTY CONTACT YOUR SALES REPRESENTATIVE FOR WARRANTY INFORMATION OV1013 | 15... - Page 16 OV1013 USER GUIDE Part No. 80161 Rev 052417...
