- Page 1 OV1001 | Part No. 23620 OV1001 HEIGHT ADJUSTABLE TABLE USER GUIDE...
- Page 2 HEIGHT ADJUSTABLE TABLE A healthier work environment starts with the option to sit or stand throughout the day. The OV1001 table is the industry standard in height-adjustable products, and your first step towards improving the efficiency and well-being of your organization.
-
Page 3: Table Of Contents
TABLE OF CONTENTS User Guide: OV1001 TABLE OF CONTENTS Parts Diagram Full Length Independent Adjustable L-Rail Three-Leg Safety Information 10-13 Assembly Instructions Operation 14-15 Initialization and Reset Handswitch Operation Programmable Handswitch Operation - Change the Height Unit - Adjust Height Display... -
Page 4: Parts Diagram
PARTS DIAGRAM User Guide: OV1001 OV1001 PARTS DIAGRAM FULL LENGTH For tables up to 84" PARTS Qty/Package 1. J-Rail 2. Column 3. Top Support 4. Foot 5. M6x1.0 12mm Screw 6. Handswitch Control Box 8. Power Cord 9. M10x1.5 20mm Screw 10. -
Page 5: Independent
PARTS DIAGRAM User Guide: OV1001 INDEPENDENT For tables 60" or Less PARTS Qty/Package 1. Column 2. Top Support 3. Foot 4. Control Box 5. Handswitch 6. Power Cord M10x1.5 20mm Screw 8. M6x1.0 12mm Screw 9. Glide OV1001 | 5... -
Page 6: Adjustable L-Rail
PARTS DIAGRAM User Guide: OV1001 ADJUSTABLE L-RAIL For tables up to 84” PARTS Qty/Package 1. Column 2. Top Support 3. Foot 4. Adjustable L-Rail 5. Control Box 6. Handswitch Power Cord 8. M10x1.5 20mm Screw 9. M6x1.0 12mm Screw 10. Glide... -
Page 7: Three-Leg
PARTS DIAGRAM User Guide: OV1001 THREE-LEG PARTS Qty/Package 1. Column 2. Top Support 3. Foot 4. J-Rail 5. Left Hand Adapter Bracket 6. Right Hand Adapter Bracket Third Leg Bracket 8. Control Box 9. Power Cord 10. Handswitch 11. M6x1.0 12mm Screw 12. -
Page 8: Safety Information
SAFETY INFORMATION User Guide: OV1001 SAFETY INFORMATION IMPORTANT SAFETY INSTRUCTIONS Save these instructions. DANGER To reduce the risk of electric shock: Always unplug this furnishing from the electrical outlet before cleaning. WARNING: To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product. - Page 9 SAFETY INFORMATION User Guide: OV1001 DO NOT OVERLOAD DESK To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability and lead to tip over.
-
Page 10: Assembly Instructions
The assembly of the table frame to be made in accordance with this manual. Changes to the table frame or improper use may affect the safety, function, and life of your product. This manual is for all sit-stand tables from the OV1001 series. Due to different models or types, pictures may vary. - Page 11 ASSEMBLY INSTRUCTIONS User Guide: OV1001 ASSEMBLE THE COLUMN TO THE J-RAIL Assemble using the M6x1.0 12mm length screws (6 per column). The maximum tightening torque for these screws is 9.9Nm (7.3 ft-lbs) ASSEMBLE THE TOP SUPPORT TO THE COLUMN Assemble using the M6x1.0 12mm length screws (2 per top support).
- Page 12 ASSEMBLY INSTRUCTIONS User Guide: OV1001 FASTEN THE TABLE FRAME ONTO THE TABLE TOP Be sure to use approved screws per the table top supplier. FULL LENGTH INDEPENDENT ADJUSTABLE L-RAIL THREE-LEG Please make sure top supports are mounted 1.5" from edge of work surface.
- Page 13 ASSEMBLY INSTRUCTIONS User Guide: OV1001 FASTEN THE CONTROL BOX AND HANDSWITCH TO THE TABLE TOP Make sure the control box and handswitch are fastened in a location where all the cables will connect without being in tension. Be sure to use approved screws per the table top supplier.
-
Page 14: Operation
OPERATION INFORMATION User Guide: OV1001 OPERATION INFORMATION INITIALIZATION/RESET The desk must be initialized/reset after any of the following: - After assembly - After disconnection from the power supply - After any impact on the table top. To initialize/reset, move the table to the lowest position by pressing the DOWN button on the handswitch until the columns reach the lowest position. -
Page 15: Change The Height Unit
OPERATION INFORMATION User Guide: OV1001 PROGRAMMABLE HANDSWITCH OPERATION (continued) CHANGE THE HEIGHT UNIT (inches or centimeters) The handswitch can display the table height in either centimeters or inches. With the help of the S5-menus, the unit of measure can be changed. -
Page 16: Troubleshooting
TROUBLESHOOTING User Guide: OV1001 TROUBLESHOOTING UNIT ERROR CODE SOURCE SOLUTION No power supply Plug in the power cord or check the connection Table does not on the control box move No connection or a loose Verify the plug connections of the motor cable... -
Page 17: Handswitch Errors
TROUBLESHOOTING User Guide: OV1001 HANDSWITCH DISPLAY ERROR CODE SOURCE SOLUTION The control box monitors the duty cycle (time-controlled) and its max Wait until the “HOT” display goes out - the table is working properly again temperature. A value has been exceeded. -
Page 18: Technical Data
TECHNICAL DATA User Guide: OV1001 TECHNICAL DATA GENERAL CONTROL BOX Power supply 120 VAC ±10% / 60 Hz Standby power consumption, primarily <0.3 W Operating temperature 0-35°C Protection class IP 20 Maximum power output 216VA/24V TWO-COLUMN FRAME WITH CONTROL BOX Maximum lift capacity 225 lb (≈... -
Page 19: Standards & Certifications
CUSTOMER SERVICE User Guide: OV1001 STANDARDS & CERTIFICATIONS The drive system is tested according to the following standards: UL 962 Issued: 2014/11/07 Ed: 4 Household and Commercial Furnishings CSA C22.2#68 Issued: 2009/09/01 Ed: 7 (R2014) Motor-Operated Appliances (Household and Commercial) Meets BIFMA X5.5 2014. - Page 20 OV1001 USER GUIDE Part No. 23620 Rev E | Rev 061919...
