OV1022 | Part No. 118101 OV1022 HEIGHT ADJUSTABLE TABLE USER GUIDE...
Page 2
PRODUCT OVERVIEW User Guide: OV1022 OV1022 HEIGHT ADJUSTABLE TABLE FEATURES • Full table base (add your own work surface) • Over 150 color options • Rated at 225 lb. load per two-column kit • Integrated wire management 2 | OV1022...
TABLE OF CONTENTS User Guide: OV1022 TABLE OF CONTENTS Parts Diagram Full Length 48" Full Length 54"-72" Safety Information Assembly Instructions 8-12 Operation 13-14 Initialization and Reset Handswitch Operation Programmable Handswitch Operation - Change the Height Unit - Adjust Height Display - Save Memory Position - Recall Memory Position Troubleshooting...
PARTS DIAGRAM User Guide: OV1022 OV1022 PARTS DIAGRAM FULL LENGTH For tables 48" PARTS Qty/Package 1. Column 2. Leg 3. Glide 4. 1- Piece J-Rail with Cable Tray 5. M6x12mm Screw 6. Top Support Programmable Handswitch 8. Power Cord 9. Control Box 10.
PARTS DIAGRAM User Guide: OV1022 OV1022 PARTS DIAGRAM FULL LENGTH For tables 54"-72" PARTS Qty/Package 1. Column 2. Leg 3. Glide 4. 3-Piece Adjustable J-Rail with Cable Tray 5. M6x12mm Screw 6. M6 Wing Nut Top Support 8. Programmable Handswitch 9.
To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product. Do not change or replace components and accessories provided by OMT-Veyhl. INSTALL ONLY APPROVED WORK SURFACES This table system does not include a work surface (desktop).
Page 7
SAFETY INFORMATION User Guide: OV1022 DO NOT OVERLOAD DESK To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability and lead to tip over.
ASSEMBLY INSTRUCTIONS User Guide: OV1022 ASSEMBLY INSTRUCTIONS The assembly of the table frame to be made in accordance with this manual. Changes to the table frame or improper use may affect the safety, function, and life of your product. This manual is for all sit-stand tables from the OV1022 series. Due to different models or types, pictures may vary.
Page 9
ASSEMBLY INSTRUCTIONS User Guide: OV1022 ASSEMBLE THE TOP SUPPORT TO THE COLUMN Assemble using the M6x12mm length screws (2 per top support). The maximum tightening torque for these screws is 9.9Nm (7.3 ft-lbs) ASSEMBLE THE COLUMN TO THE J-RAIL Assemble using the M6x12mm length screws (2 per column).
Page 10
ASSEMBLY INSTRUCTIONS User Guide: OV1022 ASSEMBLE THE LEG TO THE COLUMN Assemble using the M8 hex nuts (2 per leg). The maximum tightening torque for these is 24Nm (17.7 ft-lbs). PRE-INSTALL THE HEX NUTS M8 Hex Nut Partially install the M8 hex nuts onto column studs (about halfway).
Page 11
ASSEMBLY INSTRUCTIONS User Guide: OV1022 FASTEN THE TABLE FRAME ONTO THE TABLE TOP Center frame on the table top, ensuring that top supports are of equal distance from the work surface's edge. Be sure to use approved screws per the table top supplier. Top supports should be mounted 3"...
Page 12
ASSEMBLY INSTRUCTIONS User Guide: OV1022 CONNECT THE HANDSWITCH (HS) CABLE TO THE CONTROL BOX CONNECT THE SUPPLIED POWER CORD (AC) TO THE CONTROL BOX ATTACH ALL CABLES TO THE TABLE TOP AND/OR PLACE IN CABLE TRAY. Attach cables in order to avoid any damage during operation.
OPERATION INFORMATION User Guide: OV1022 OPERATION INFORMATION INITIALIZATION/RESET The desk must be initialized/reset after any of the following: - After assembly - After disconnection from the power supply - After any impact on the table top. To initialize/reset, move the table to the lowest position by pressing the DOWN button on the handswitch until the columns reach the lowest position.
OPERATION INFORMATION User Guide: OV1022 PROGRAMMABLE HANDSWITCH OPERATION (continued) CHANGE THE HEIGHT UNIT (inches or centimeters) The handswitch can display the table height in either centimeters or inches. With the help of the S5-menus, the unit of measure can be changed. To change the unit of measure, follow these steps: 1.
TROUBLESHOOTING User Guide: OV1022 TROUBLESHOOTING UNIT ERROR CODE SOURCE SOLUTION No power supply Plug in the power cord or check the connection Table does not on the control box move No connection or a loose Verify the plug connections of the motor cable connection to the drives to the control box No connection or a loose...
TROUBLESHOOTING User Guide: OV1022 HANDSWITCH DISPLAY ERROR CODE SOURCE SOLUTION The control box monitors the duty cycle (time-controlled) and its max Wait until the “HOT” display goes out - the table is working properly again temperature. A value has been exceeded. M1 –...
TECHNICAL DATA User Guide: OV1022 TECHNICAL DATA GENERAL CONTROL BOX Power supply 120 VAC ±10% / 60 Hz Standby power consumption, primarily <0.3 W Operating temperature 0-35°C Protection class IP 20 Maximum power output (rated) 240 watts TWO-COLUMN FRAME WITH CONTROL BOX Maximum lift capacity 211 lb (≈...
WARRANTY CONTACT YOUR SALES REPRESENTATIVE FOR WARRANTY INFORMATION INTERTEK LISTING BELONGS TO: System: Lambda OMT-Veyhl USA 11511 James Street Holland, MI 49424 End of life cycle: Once product is disassembled, all steel components can be recycled at your local metal collector. For products with electronic components, see Disassembly Guide.
