Connections

How to connect the PD-01.
Open cover of battery
1.
compartment and insert battery
Take care to snap the battery to the
connector with correct polarity.
ZOOM Power Drive PD-01
6
Turn amplifier off and connect cable
2.
to guitar
Make sure that the
plug is inserted fully
into the OUT jack of
the guitar.
Plug cable from guitar into IN jack
3.
of PD-01
Insert the cable from the guitar
into the IN jack of the PD-01.
This turns the PD-01 on.
