IN jack
1
The input of the unit acts as a power switch. When you connect the plug of the cable from the guitar here, the unit is turned on.
OUT jack
2
This is the output of the unit. Connect the plug of the cable going to the guitar amplifier or other effect device here.
AC adapter jack
3
When powering the unit from the AC adapter, insert the plug from the adapter into this jack. Be sure to use only an AC adapter rated for 9 V
DC, center negative, 300 mA (Zoom AD-0006). When the AC adapter is connected, the PD-01 will always be ON, regardless of whether a
cable is plugged into the IN jack.
GAIN control
4
Turning this control clockwise increases the drive effect. In the zero position, there is no distortion.
LEVEL control
5
This control adjusts the output signal level. Turning the control clockwise increases the level.
HIGH control
6
This control adjusts the high frequency range.
LOW control
7
This control adjusts the low frequency range.
Indicator
8
Illuminates when the PD-01 is active.
Foot switch
9
Switches the PD-01 effect on and off.
Battery compartment
10
A 9V battery (6F22) can be inserted here.
ZOOM Power Drive PD-01
5
