CENTURION SYSTEMS D3 Installation Manual page 10

44 44
L C
300mm
400mm
MECHANICAL MOUNTING DETAILS
Option 2 - Set into concrete plinth
- Ensure motor does not protrude into drive-way install baseplate
with centre line 250mm off pillar centre.
- Fasten concrete anchors (44) to the baseplate (43) using the M10x45
bolts provided. Ensure that the bolts are well tightened.
- Position baseplate (43) with centre of single support stud (45) 105mm
from edge of gate (46). (This dimension assumes centre line of rack (47)
is 20mm from edge of gate).
43 43
45 45
44 44
2 5 0 m
m
4 0 0 m m
8
43 43
105mm
20mm
47 47 46 46
L C
