Temperzone Unit Controller 6 - Operation and installation- Hydronic
When the UC6 is configured indoor fan as EC motor:
Terminal Signal
Low1
No function.
Low2
Med1
No function.
Med2
Hi1/Hi2
Active to turn on the EC fan contact
Terminal Signal
CMC1
Compressor On/Off
CMC2
Circulation pump control
RV1
Reversing valve/Electric heater
circuit1(if fitted)
RV2
Condensate pump
CCH
Crankcase Heater/Electric heater
circuit2(if fitted)
CCS
Water Pump
3.3.
Input terminals
Terminal Signal
CS
This input can have one of two
functions:
(1)
(2)
ST1
Compressor suction line
temperature
ST2
NA
DT1
Compressor discharge line
temperature
DT2
Electric heater temperature
sensor (if used)
0 to 1V Analogue input
Return or supply air
temperature
Notes
For variable capacity systems
For
NTC
NTC
Page 7 of 21
Notes
Notes
When active these outputs
electrically connect to the
Output supply terminal.
fixed capacity systems
blue wires
red wires
Issue 1
