3.1.

Power supply terminals

The UC6 is powered by 24V ±10% AC. A class 2 safety transformer with a
minimum rating of 24VA must be used in the installation. The power supply to the
UC6 controller must not be used to power other electrical devices. If the 24V
secondary winding of the transformer is earthed then make sure that the earthed
wire connects to terminal "µPC supply 0V".
A yellow LED indicates when the UC6 is powered.
Terminal
HOT
(µPC supply)
0V
(µPC supply)
Output supply
Fan supply
3.2.

Output terminals

When the UC6 is configured as three speed indoor fan:
Terminal Signal
Low1 Indoor fan(s) Low speed terminal
Low2
Med1 Indoor fan(s) Medium speed terminal
Med2
Hi1 Indoor fan(s) High speed terminal
Hi2
Signal
24V AC HOT
24V AC COMMON
Relay common power supply for
switched output signals:
CMC1
RV1
CCH
Power supply for fan control
terminals.
Notes
Do not inadvertently connect
230V AC to these pins!
This terminal normally
connects to 230V AC phase.
CMC2
RV2
CCS
Depending on the
connections to the fan or fan
controller this terminal
normally connects to
or
Page 6 of 21
24V AC HOT
230V AC phase
Notes
When active these outputs
electrically connect to the
Fan supply terminal.
