- Page 1 Temperzone Unit Controller 6 - Operation & Installation Issue 1 UNIT CONTROLLER 6 (UC6) Operation and Installation Date: 1 November 2012 Issue: 1 Page 1 of 18...
-
Page 2: Table Of Contents
Temperzone Unit Controller 6 - Operation and installation Issue 1 Contents Introduction ............................3 Features ............................. 3 Lower board connections ........................4 3.1. Power supply terminals ......................5 3.2. Output terminals ......................... 5 3.3. Input terminals ..........................6 Upper board connections........................8 4.1. -
Page 3: Introduction
Temperzone Unit Controller 6 - Operation and installation Issue 1 1. Introduction The temperzone Unit Controller 6 (UC6) is the successor to the OUC4 controller. The UC6 provides increased capability and flexibility in indoor-, outdoor- and packaged units. The complete controller combines the µPC controller board from Carel plus an interface board to connect temperzone standard sensors and plugs. -
Page 4: Lower Board Connections
Never run power cables and signal cables in the same conduits. Contact temperzone if the controller has malfunctioned. Do not attempt to repair the controller. Page 4 of 18... -
Page 5: Power Supply Terminals
Temperzone Unit Controller 6 - Operation and installation Issue 1 3.1. Power supply terminals The UC6 is powered by 24V ±10% AC. A class 2 safety transformer with a minimum rating of 24VA must be used in the installation. The power supply to the UC6 controller must not be used to power other electrical devices. -
Page 6: Input Terminals
Temperzone Unit Controller 6 - Operation and installation Issue 1 When the UC6 is configured NOT to control indoor fan speed: Terminal Signal Notes Low1 System 1 indoor fan off during an outdoor coil de-ice cycle. Low2 When active these outputs... - Page 7 Temperzone Unit Controller 6 - Operation and installation Issue 1 Terminal Signal Notes Compressor 1 suction line 0-5V transducer pressure Compressor 2 suction line pressure Compressor 1 discharge line pressure Compressor 2 discharge line pressure Compressor 1 outdoor(mid) coil Mid-coil: yellow wires...
-
Page 8: Upper Board Connections
Temperzone Unit Controller 6 - Operation and installation Issue 1 4. Upper board connections The digital input port common pins DIC1 and DIC2 are internally directly connected to the local board 0V. 4.1. Digital input signals When the UC6 is configured to control indoor fan speed:... -
Page 9: Digital Output Signals
Temperzone Unit Controller 6 - Operation and installation Issue 1 When the UC6 is configured for DRED function: Signal Notes When activated the compressors will be OFF. DRED1 The indoor fan is allowed to continue. DRED2 active: Total unit energy... -
Page 10: Communication Ports
4.4.1. Temperzone TZT-100 thermostat connection The UC6 can connect directly to the temperzone TZT-100 thermostat using a shielded cable with two twisted pair wires suitable for RS85 serial communications. The drawing below shows connection details. -
Page 11: Electronic Expansion Valves
The UC6 can control a unit where one of the two compressors is a variable speed compressor or a digital scroll compressor. Temperzone pre-configures the unit to the correct compressor type; a UC6 service tool is required if the compressor type configuration must be changed. -
Page 12: Outdoor Fan Control
DI1: Low o DI2: Medium o DI3: High If the system uses a temperzone TZT-100 thermostat then the indoor fan input signals are received from the TZT-100 through the RS485 communications cable. Two types of outputs are available for indoor fan speed control:... -
Page 13: Outdoor Coil De-Ice Control
The UC6 will not allow both systems to de-ice at the same time. Exceptions to this rule exist, for example for units with a common outdoor fan chamber must de-ice the two outdoor coils at the same time. Temperzone configures each unit to the correct de-ice strategy. -
Page 14: Electronic Expansion Valve Control
Display indication when timer is active number 6.3. Minimum compressor cycle time A compressor is allowed a maximum of 10 starts per hour (one start per 6 minutes). This limits the amount of stress on the compressor motor. Display indication when timer is active number... -
Page 15: Delay Time Between Compressor 1 And Compressor 2 Start
Temperzone Unit Controller 6 - Operation and installation Issue 1 6.4. Delay time between compressor 1 and compressor 2 start The UC6 does not allow both compressors in the unit to start at the same time even when the compressor run request is received at the same time; a brief time delay (normally 40 seconds) is inserted. -
Page 16: Indoor Coil Frost Protection (Frost)
Temperzone Unit Controller 6 - Operation and installation Issue 1 6.7. Indoor coil frost protection (FROST) When the unit is cooling the evaporating temperature in the indoor coil must remain above -10°C (adjustable from -10°C to -2°C by using a UC6 service tool). -
Page 17: Sensor Alarm
Temperzone Unit Controller 6 - Operation and installation Issue 1 6.10. Sensor alarm If the signal of a temperature sensor or pressure transducer is out of normal operating range the UC6 will generate an alarm. The sensor may be faulty, disconnected or short circuit. -
Page 18: Display Summary
Temperzone Unit Controller 6 - Operation and installation Issue 1 9. Display summary Description Notes Section Normal operation Compressor timer active Compressor is held OFF until timer expires Compressor timer active Compressor is held ON until timer expires Loss of refrigerant alarm...
