Temperzone Unit Controller 6 - Operation and installation- Hydronic
When the UC6 is configured for DRED function:
DI Signal
8 DRED1
DRED2 or DRED3
9 (configurable via UC6
service interface)
DI Signal
10 Push button
4.2.

Digital output signals

DO Signal
NO7 Normally open
C3 Common
NC7 Normally closed
4.3.

Analogue output signals

AOUT Signal
Y1 Indoor fan speed
Y2 Water flow Valve
Y4 LED display control
Notes
When activated the compressors will be OFF.
The indoor fan is allowed to continue.
DRED2 active:
consumption will be reduced to less than
75% of rating.
DRED3 active:
consumption will be reduced to less than
50% of rating.
Notes
Press and hold the push button on the lower
board 1 to 5 seconds to start test mode.
Test mode can only be activated when both
compressors are OFF.
Press and hold the push button on the lower
board 10 to 15 seconds to start
commissioning mode.
Notes
Alarm output relay
Notes
0-10V (if used)
0-10V control water flow
Controls the 1-digit LED display used to
show alarm codes.
Page 10 of 21
Total unit energy
Total unit energy
Issue 1
