- Page 1 JUMO dTRANS T09 AS Cable transmitter for temperature Operating Manual 70709000T90Z001K000 V1.00/EN/00733462/2020-03-03...
-
Page 3: Table Of Contents
Setup program..........12 JUMO dTRANS T09 AS, type 707090 (two-wire 4 to 20 mA) ......12 Hardware and software requirements. -
Page 4: Introduction
Introduction 1 Introduction Safety information General This manual contains information that must be observed in the interest of your own safety and to avoid material damage. This information is supported by symbols which are used in this manual as indicated. Please read this manual before starting up the device. -
Page 5: Description
The cable transmitter's high level of vibration and shock resistance makes it reliable and durable. It is connected on the input and output side via M12 plug connectors. JUMO dTRANS T09 AS: cable transmitter for temperature with analog output. Connection elements... -
Page 6: Identifying The Device Version
Identifying the device version 2 Identifying the device version Nameplate Position The nameplate is located on the housing surface. dTRANS T09 AS 36039 Fulda Germany TN 00123456 MB -XX...+XXX°C D C 8 . . . 3 5 V 4...20mA F-Nr.: 12345678901YYWW6789 Device name Part no. -
Page 7: Order Details
1013 1× Pt1000 in four-wire circuit In the JUMO dTRANS T09 AS version the output is scaled to 0 to 100 °C per default. For the overview of the default configuration see "Configurable parameters ", Page 12. If feature Pt100 is selected, the connection of a Pt1000 sensor is not possible. Likewise, if feature Pt1000 is select- ed, the connection of a Pt100 sensor is not possible. -
Page 8: Accessories
2 Identifying the device version Accessories Designation Part no. Connecting cable 500 mm 00638312 M12 connecting cable (input side) (PUR), 1 500 00638313 5-pole (shielded) Connecting cable Connecting cable (PVC), (output side) with socket M12 × 1, 00404585 4-pole, 2000 mm Cable socket M12 ×... -
Page 9: Mounting
Mounting 3 Mounting The cable transmitter may only be installed, connected and started up by qualified and authorized per- sonnel observing these operating instructions, the applicable standards, and the legal requirements (de- pending on the application). If you experience difficulties during installation and startup, please contact the manufacturer. The device can be installed in any position. -
Page 10: Electrical Connection
Electrical connection 4 Electrical connection Input RTD temperature probe Electrical connection M12, A-coded, socket, Terminal assignment 4-pole according to DIN EN 61076-2- RTD temperature probe in four-wire circuit Top view of the M12 plug connector from the associated RTD temperature probe! Output Machine connector M12 ×... -
Page 11: Connection Examples
4 Electrical connection Connection examples Connection example Controller Indicator Recorder with power supply unit temperature probe with Supply unit transmitter DC 8 35 V 20 mA Connecting example Controller Indicator Recorder with supply isolator temperature probe with Supply transmitter isolator 20 mA 20 mA... -
Page 12: Setup Program
Setup program 5 Setup program JUMO dTRANS T09 AS, type 707090 (two-wire 4 to 20 mA) The setup program is used for configuring the transmitter using a PC. For this purpose the following is required: • Please only use the configuration line, 4-pole with connector and socket M12 × 1, and Western plug RJ-45 with part no. -
Page 13: Hardware And Software Requirements
The PC interface with USB-TTL converter is only designed for service use over a limited period, such as the transfer of setup data. It links JUMO devices to a PC through a galvanically isolated connection. The Western plug RJ-45 is intended specifically for JUMO devices and not for third-party equipment. - Page 14 5 Setup program PC/laptop connection (setup program Part no. 00485016) USB type A plug USB type B plug PC interface with USB/TTL converter Part no. 00456352 (with USB cable) RJ-45 Western plug 2000 ( i ) ( j ) brown (+) PIN 1 DC 8 to 35 V blue (-) PIN 3 white...
-
Page 15: Technical Data
Technical data 6 Technical data Input RTD temperature probe Pt100 (DIN EN 60751:2009 / IEC 60751:2008) in four-wire circuit or Pt1000 (DIN EN 60751:2009 / IEC 60751:2008) in four-wire circuit Measuring range -50 to +260 °C Smallest measuring span 10 K Sampling rate 1 measurement per second Input filter... -
Page 16: Electrical Data
Protection type with mating connec- IP66, IP67, and IP69 according to DIN EN 60529 Installation position Weight JUMO dTRANS T09 AS, type 707090 = ca. 35 g JUMO dTRANS T09 DS, type 707091 = ca. 43 g Potential equalization Functional bonding conductor FB The temperature probe must be connected to the plant's potential equalization system via the process connection. -
Page 17: China Rohs
China RoHS 7 China RoHS Product group: 707090 China EEP Hazardous Substances Information Component Name （ ） （Hg ) （ ） （ ） （ ） （ ） Cr(VI) PBDE ○ ○ ○ ○ ○ ○ Housing (Gehäuse) ○ ○ ○ ○... - Page 18 7 China RoHS...
- Page 20 JUMO GmbH & Co. KG JUMO Instrument Co. Ltd. JUMO Process Control, Inc. Street address: JUMO House 6733 Myers Road Moritz-Juchheim-Straße 1 Temple Bank, Riverway East Syracuse, NY 13057, USA 36039 Fulda, Germany Harlow, Essex, CM20 2DY, UK Delivery address:...
