Before You Assemble; Hardware And Tool Guide - Bowflex SelectTech 5.1 Owner's/Assembly Manual

Before You Assemble

Before You Assemble
Please take the time to read all assembly instructions before
attempting to assemble your Bowflex
The best place for your Bowflex
hard, level surface .

Hardware and Tool Guide

Tools Required:
• 9/16 Socket
• 9/16 Wrench or Adjustable wrench
Hardware:
Descr: Flat Washer 3/8"
Qty: 7
Descr: Flat Washer 5/16"
Qty: 10
Descr: Lock Nut 3/8"
Qty: 2
SelectTech 5 . 1 Bench .
® ®
SelectTech 5 . 1 Bench is on a
® ®
• 7/32 Allen Wrench (provided)
• 3/16 Allen Wrench (provided)
Descr: Allen Bolt - 3/8 x 3
Qty: 2
Descr: Allen Bolt - 5/16 x 2 .5
Qty: 10
Descr: Allen Bolt - 3/8 x1
Qty: 3
Basic Assembly Principles
Here are a few basic tips that will make your assembly of the
Bowflex SelectTech 5 . 1 Bench quick and easy . By using these
® ®
principles, you can simplify each process and save yourself extra
time and effort .
1 . To make the assembly process go faster, gather the pieces
you need for each step and thoroughly read the assembly
instructions for that step prior to starting assembly for the
step .
2 . When tightening a locknut on a bolt, use a combination
wrench to grip the locknut and ensure that it is fastened
securely .
3 . When attaching two pieces, gently lift and look through the
bolt holes to help guide the bolt through the holes .
4 . As a general rule, and for all bolts and nuts on your Bowflex
SelectTech 5 . 1 Bench, turn bolts or nuts toward the right
®
(clockwise) to tighten and left (counterclockwise) to loosen .
Descr: End Cap 3/4"
Qty: 2
NOTE: Illustrations not to scale.
®
