Draper AeroLift 35 Instructions Manual

AeroLift 35 220V
Ceiling-recessed projector lift with a 35 lb
Overview - Components
1. Optional Closure Panel with threaded rods to
attach to bottom/travelling pan of lift
2. Mounting Brackets
3. Traveling Pan
4. Electrical Junction Box
Please Note: Projector
not included.
CAUTION
Read and understand
all warnings
(Page 2
before
of this document)
beginning installation.
Overview - Planning
1. Based on screen location and projector
specifications, determine proper position for
projector installation.
2. Confirm that there is adequate space
for installation and operation. Minimum
clearance above ceiling level varies
according to height of projector, optional
projector mounting bracket, optional ceiling
closure and optional Environmental Housing.
Contents
Overview - Components & Planning...................................................................1
Section 1 - Hanging Unit ......................................................................................2
PLEASE READ - Safety Information ....................................................................2
Section 2 - Installing Optional Environmental Air Space Housing ...............3
Section 3 - Installing Projector ...........................................................................3
Section 4 - Electrical Connections .....................................................................4
lifting capacity
(16kg)
2
1
3. Arrange to provide service access to the unit.
4. When installed with Environmental Air Space
Housing unit is suitable for use in an environmental
air space in accordance with Section 300.22
the National Electrical Code, and Section 2-128,
12-010 and 12-100 of the Canadian Electrical
(3)
Code, Part 1, CSA C22.1.
5. Total capacity of lift is 35 lbs
closure, projector, and bracket.
INSTRUCTIONS
INSTALLATION & OPERATION
2
2
of
(C)
, including
(16kg)
Section 5 - Wiring Diagrams ................................................................................4
Section 6 - Operation............................................................................................5
Section 7 - Testing Safety Limit Switches .........................................................5
Section 8 - Adjustments .......................................................................................6
Section 9 - Installing Ceiling Closure .................................................................7
Section 10 - Dimensions ......................................................................................8
If you have any difficulties installing or servicing your
Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385
draperinc.com | 765.987.7999 | 800.238.7999
© 2020 All Rights Reserved
2
4
3
Projector mount optional
As Soon As AeroLift 35 Arrives
1. Open carton and inspect for damage.
2. Locate the following parts:
A. The unit itself
B. Controls
C. Any optional equipment
AeroLift 35, call your dealer or Draper, Inc.
|
FORM: AeroLift35_220V_Inst20
