Operation

Control panel

Using the Geberit Monolith Plus
When a user approaches the sanitary module, the orientation light lights up and the odour
extraction unit starts up. To release a flush, press the <Large flush volume> actuator button for
a large flush or the <Small flush volume> actuator button for a small flush.
The button functions may be temporarily blocked due to high electrostatic discharges.
If the odour extraction unit indicator light permanently lights up red, the filter must be
replaced. → See "Replace the filter", page 16.
Starting or stopping the
odour extraction unit
▶
Press the <Odour extraction> button.
✓ The odour extraction unit starts
or stops. While the odour
extraction unit is running, the
odour extraction unit indicator
light blinks slowly.
The odour extraction unit shuts off
automatically after 10 minutes
(factory setting).
27021601385611403-1 © 04-2020
968.239.00.0(03)
1 Orientation light
2 Odour extraction unit indicator light
3 <Small flush volume> button
4 <Large flush volume> button
5 <Odour extraction> button
