Product description

System description
The sanitary module is equipped with user detection, an odour extraction unit and an
orientation light.
Soft-touch buttons are integrated in the cistern lid and can be used to release a large or small
flush or activate the odour extraction unit.
The integrated odour extraction unit neutralises unpleasant odours in the WC ceramic
appliance.
Technical data and conformity
Technical data
Nominal voltage
Mains frequency
Frequency range
Maximum output power
Wireless technology
Operating voltage
Power consumption
Power consumption standby
Mains connection
Flow pressure range
Flush volume, factory setting
Simplified EU Declaration of Conformity
Hereby, Geberit International AG declares that the radio equipment type Geberit Monolith Plus
is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://doc.geberit.com/968980000.pdf.
12
100–240 V AC
50–60 Hz
5.75–5.85 GHz
≤ 7 dBm EIRP
Short Range Radar Sensor
4.1 V DC
5 W
< 0.5 W
Direct connection via system plug with
flexible three-wire sheathed cable
0.1–10 bar
10–1000 kPa
6 and 3 l
