Shure Microflex Complete User Manual page 5

1. Unzip the zip file containing the Firmware
Update Library folder and a FUU folder to the
desktop or another convenient location on the
PC.
2. Connect the PC to the CCU using a LAN cable
and switch on power.
3. Browse to the folder
'MXC_Firmware_Update_Utility_xxx'
And open the folder
4. Start MXC Firmware Update Utility (FUU)
double-clicking the icon.
5. The FUU starts.
The FUU application will automatically find the
folders with the firmware releases and the
language files.
6. Select to use Ethernet connection.
Check the Ethernet settings by selecting
'Ethernet connection to CCU'.
Type the CCU IP address in IP address field.
Use IP port 3142.
7. The FUU will now show all units in the system
as well as information about the CCU.
Shure Incorporated
5
