Page 2 In order to improve the performance of the product without prior notice to the product may be a firmware upgrade. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 3: Table Of Contents
2. Change user password 18 3. Language setting 20 4. Date and Time setting 20 5. Firmware upgrade 21 6. Factory default 23 HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 4 3. System Trigger setting 54 4. Schedule setting 55 5. Event Action setting 58 7 Statistics 78 1. Counting 78 2. Report 78 8 AI Marketing 80 HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 5 9 Other Menu 84 1. Search 84 2. Display 85 3. System 87 10 Face Recognition 89 11 License Plate Recognition 95 HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 6: Safety Instruction
● Do not connect multiple devices to a single adapter, Exceeding the capac ity may cause abnormal heat generation or fire ● Keep products away from excessive dust or flammable substances (e.g.: pr opane gas) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 8: Warning
Doing so may cause personal injury due to fire, electric shock, or falling objects HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 9: Key Features
● Equipped rule engine to detect various situations and actions such as ‘ Intrusion’, ‘Occupancy’, ‘Loitering’, ‘Enter/Exit’, ‘Line Crossi ng’ HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 10 ● Receive up to 16 channels of network video ● Receive Full HD video up to 480 fps, 4K video up to 120fps HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 11: Components
2. Names and functions of front panel Status sign L List Description Red light blinks during the boot phase and green light d POWER uring operation. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 12: Name And Functions Of Rear Panel
ETH2 port or turns off when communication is not tak ing place. 3. Name and functions of rear panel ● 4CH ● 8CH / 16CH HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 13 ALARM IN Alarm input signal line terminal. ⑥ REPLAY Relay connection terminal. ⑦ RS485 RS485 communication device connection terminal. ⑧ DC12V 12V adapter plug HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 14: Basic Connection Configuration
2. Network setting ● Basic requirements of Web Name Description Recommended Browser Google Chrome, FireFox, MS Edge Window / Mac / Linux ≥1GB HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 15 Web of the router). IP address: https://<AI Box IP>:8443 (e.g.: https://10.10.10.10:8443) ID: ADMIN Password: 1234 NOTE: Make sure to use ‘https://’ (Hypertext Transfer Protocol Secure HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 16 The tool also discovers and configures other devices such as IP cameras, NVR and DVR. 1) Click the 'Search' button to search the AI BOX connection to the net work. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 17 You can determine the AI BOX from the model information and click on the product you want to set up in the list. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 18 4) After a short period of time, the list will be updated automatically and the network configuration is completed by confirming that the se ttings are correct. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 19 Note: This is a completely safe procedure as the user is only connecting to AI BOX HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 20 * It is recommended to change password for safety purposes. To increase secur ity of the device, it is recommended to change to a strong password and reset regularly. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 21: Network Setting
Enable or disable the Dynamic Host Configuration Protocol (DHCP) server. DHC P automatically assigns an IP address to the device if there is a DHCP serve r on the network. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 22 - Gateway: Input the gateway value of the device or router that accesses other networks such as Internet/WAN. - 1st DNS: Input the 1st DNS value of the device. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 23: Change User Password
Use the Users & User Management page to create and manage user accounts and to change the way the AI BOX manages the user settings. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 24 Input your current password and new password then press the 'APPLY' bu tton. ✓ Current password: Input the current password for user account ✓ New password: Input new password HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 25: Language Setting
You need to log in again with your new password if you change the pass word. 3. Language setting Set the language which will be displayed on the system. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 26: Date And Time Setting
※ The DNS address of the device must be set correctly if the address of NPT server is a domain. Auto Sync: Select whether to synchronize the time periodically through the NTP server. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 27: Firmware Upgrade
● Time zone / DST Time zone: Select your timezone. DST: Choose whether to use daylight saving time. 5. Firmware upgrade Upgrade device’s firmware. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 29 Attach the firmware file (*.bin) to upgrade Press the ‘Start’ button to start the firmware upgrade The device will reboot when the firmware upgrade is complete HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 30: Factory Default
(DHCP) network, the IP address settings for the AI BOX will be lost an d the server will not recognize the camera. DHCP On is the default setting f or the AI BOX IP address HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 32: Video Source Setting
30 fps. In other words, you should connect the cable at a lower fps to 7 fp s or less to connect all channels when connecting a 4K camera. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 33 Press the 'Discovery' button to search ONVIF devices connected to the lo cal network. Input the account information of the device found and press the <Login> button to view the video stream address. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 34: Ai Algorithm
The default installed algorithm is as follows: ● Human / Vehicle - Mid The algorithm detects medium distance of people and vehicle. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 35 4.50% 3.00% 2.25% ✓ Minimum detectable object size of Loitering, Enter / Exit and Line Cr ossing Person Vehicle width height width height HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 36: False Detection Filter Setting
(In order to exclude the detected box as follows, only the center of the object shoul d be minimized, not covering the entire box.) ⇨ 4. Face Recognition See P.00 for more information on face detection settings. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 37: Annotated Live Video
Grey: Objects in a static state. White: Objects in dynamic state. Purple: The object where the event occurred. (Appears for a few sec onds after the event) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 38: Action Rule Overview
Condition is met. It can define and perform various types of actions , including exporting alarm outputs or sending their events to the ONVIF Metadata Stream. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 39: Ai Trigger Setting
ROI set zone on the screen ([Caution] The determination of whether an object is inside a section is based on the center coordinates of the object HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 40 1) In the SETUP application tab, enter the AI Trigger menu under the 'Actio n Rules' menu. 2) Click the Intrusion tab. 3) Click the ‘Add’ button at the bottom. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 41 When the ‘check’ is enabled, only the first object that breaks into th e zone will raise an event. (Intrusion must occur again when all objects are disappeared in a zone before new events occur.) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 42 11) Counter Reset lets you set the time to reset the widget's counter. You can also reset manually by pressing the Reset button. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 43 Right click the edge of ROI to delete the edge. 14) Drag the Widget rectangle in the upper right corner to set where the wi dget will appear. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 44 [Caution] The determination of whether an object is inside a section is based on the center coordinates of the object. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 45 4) Input a Trigger preset name. 5) Select ‘Video Source’. 6) Select the discovery target class. It is possible to select multiple objects for detection. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 46 8) After the ‘Fewer than’ is set, it will trigger if the number of target s to be detected is less than the set number. 9) Show additional settings when you check for the ‘Advanced Setup’. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 47 Right click the edge of ROI to delete the edge. 13) Drag the Widget rectangle in the upper right corner to set where the wi dget will appear. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 48 ([Caution] The determination of whether an object is inside a section is based on the center coordinates of the object.) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 49 1) In the ‘SETUP’ application tab, enter the AI Triger menu under the 'Ac tion Rules' menu. 2) Click Loitering tab. 3) Click the ‘Add’ button at the bottom. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 50 7) Set the ‘Dwell Time’. Triggered when detection target stays longer tha n set time. 8) Show additional settings when you check for the ‘Advanced Setup’. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 51 You can also reset manually by pressing the ‘RESET’ button. 11) It will ignore objects that are not moving if the ‘Ignore Static Objec t’ is enabled. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 52 Right click the edge of ROI to delete the edge. 13) Drag the Widget rectangle in the upper right corner to set where the wi dget will appear. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 53 ([Caution] The determination of whether an object is inside a section is based on the center coordinates of the object.) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 54 1) In the ‘SETUP’ application tab, enter the ‘AI Trigger’ menu under th e 'Action Rules' menu. 2) Click ‘Stopping’ tab. 3) Click the ‘Add’ button at the bottom. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 55 7) Set the ‘Dwell Time’. Triggered when detection target stays longer tha n set time. 8) Show additional settings when you check for the ‘Advanced Setup’. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 56 10) ‘Count Reset’ allows you to set the time to reset the widget's count. You can also reset manually by pressing the ‘RESET’ button. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 57 Right click the edge of ROI to delete the edge. 13) Drag the Widget rectangle in the upper right corner to set where the wi dget will appear. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 58 The center coordinates can b e seen by activating the Object Trajectory option in the DISPLAY-> OSD item.) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 59 1) In the ‘SETUP’ application tab, enter the ‘AI Trigger’ menu under th e 'Action Rules' menu. 2) Click ‘Enter/Exit’ tab. 3) Click the ‘Add’ button at the bottom. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 60 - detect the target goes out of the zone. both - detect both directions. 8) Show additional settings when you check for the ‘Advanced Setup’. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 61 11) ‘Count Reset’ allows you to set the time to reset the widget's count. You can also reset manually by pressing the ‘RESET’ button. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 62 Right click the edge of ROI to delete the edge. 13) Drag the Widget rectangle in the upper right corner to set where the wi dget will appear. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 63 The center coordinates can be seen by activating the Object Trajec tory option in the DISPLAY-> OSD item.) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 64 1) In the ‘SETUP’ application tab, enter the AI Trigger menu under the 'A ction Rules' menu. 2) Click Line ‘Crossing tab’. 3) Click the ‘Add’ button at the bottom. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 65 ‘forward’–Detects the direction of the green arrow. ‘reverse’– Detects the direction of the purple arrow. ‘both’-Detects both directions. 8) Show additional settings when you check for the ‘Advanced Setup’. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 66 11) ‘Count Reset’ allows you to set the time to reset the widget's count. You can also reset manually by pressing the ‘RESET’ button. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 67 Right click the edge of ‘Polyline’ to delete the edge. 13) Drag the Widget rectangle in the upper right corner to set where the wi dget will appear. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 68: System Trigger Setting
● Alarm In Alarm In does not require a separate preset setting. Alarm In can be added dir ectly in Action Rule setting. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 69: Schedule Setting
1) In the ‘SETUP’ application tab, enter the Schedule menu under the 'Act ion Rules' menu. 2) Click the ‘Add’ button at the bottom. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 70 4) Select the day. 5) Select the start time and end time of the schedule. 6) Click the ‘APPLY’ button at the bottom to save. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 71 ※ All 24 hours will be included in the schedule if you set the same start and end time. <Weekend 24 hours setup example> ※ Please set it up like as follows if you need a schedule beyond midnight. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 72: Event Action Setting
Friday are set so the actual schedule is valid until 9:00 AM on Saturday. 5. Event Action setting Event actions are classified into three categories: Network, System, and VMS. ● Network Action Event HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 73 1) In the ‘SETUP’ application tab, enter the Action menu below the 'Actio n Rules' menu. 2) Click the ‘Email’ tab to enter the Email preset list and click the ‘A dd’ button. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 74 4) Input the email address you want to receive in ‘TO’ 5) Check the ‘Attach Snapshot’ to display the Snapshot transfer sub-setti ngs. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 75 9) Input the SMTP server address and port number. 10) Select Encryption type. 11) Select the certificate validation option for the SMTP server. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 76 13) Check the Message Example for an example of the actual message being sen 14) Click the ‘TEST’ button to confirm that the receiving test Email’s se ttings are correct. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 78 1) In the ‘SETUP’ tab, enter the ‘Event Action’ menu under the 'Action Rules' menu. 2) Click the HTTP Tab to enter the list of HTTP callback presets and click the ‘Add’ button. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 79 3) Type the name of the HTTP callback preset in the Name section. 4) Select HTTP/HTTPS protocol. 5) Input the URL of the server. 6) Check the Attach Snapshot to display the Snapshot transfer sub-settings. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 80 8) Edit the HTTP action message. You can configure the message by using a t emplate or by including an event attribute token. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 81 11) Click the ‘APPLY’ button at the bottom to save 12) Check the HTTP preset section you added in the list. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 82 1) In the ‘SETUP’ tab, enter the ‘Event Action’ menu under the 'Action Rules' menu. 2) Click the TCP Tab to enter the TCP preset list and click the ‘Add’ but ton. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 83 4) Input the host IP address or domain name where the TCP receiving server is running. 5) Input the Host port number of the TCP receiving server. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 84 9) Click the ‘APPLY’ button at the bottom to save. 10) Check the TCP preset section that you added in the list. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 85 You can also send a test message to confirm that the setting s are correct. 1) In the ‘SETUP’ tab, enter the ‘Event Action’ menu under the 'Action Rules' menu. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 86 5) Input the Host port number of the FTP receiving server. 6) Edit the Snapshot Time Range (From secs before, To secs after) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 87 8) Click the ‘TEST’ button to send the example Name to the server and che ck whether it is received. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 88 ONVIF RTSP Metadata Stream is available in the product, so do not need separat e preset settings. In the ONVIF Tab, you can see the ONVIF Topic name for each trigger type. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 89 AI BOX is an ARM state that can generate an alarm action event at any time. Ho wever, the connected controller can be changed to DISARM state to prevent alar HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 90 It is possible to set how long it will activate from the Alarm Out Duration wh en the Alarm Out action is activated. The entry default is 5 seconds. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 91 Set action rule. If you add the video popup in the action setting, the channel where the event occurred on the live screen pops up for the set time. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 92 RS485 exports action messages sequentially without using a separate protocol. This can be used by setting the default baud rate and editing the action messa HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 93 4) Click the 'TEST' button to send the example message to the server and ch eck whether it is received. 5) Click the 'APPLY' button at the bottom to save. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 94 ■ Control See video tutorial ( https://youtu.be/yDxTFfNnvmY ) ■ GenetecTM See video tutorial ( https://youtu.be/ewjL8QHgR-w ) ■ Nx See video tutorial ( https://youtu.be/QRpj3BiHfiM ) HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 95 HTTP action message. You can configure the mes sage by 4) using a template or by including an event attribute token. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 96 7) Set the trigger type and its type in the Trigger Setup step. Then sele ct Trigger Preset and click the 'NEXT' button to move to the next step HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 97 9) Click the + button to add another trigger to the condition. 10) Select the Trigger type and preset. 11) Set the Condition Trigger valid time. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 98 13) To delete the trigger added as a condition, click the trash can icon on the right. 14) When you have finished setting the condition, click the 'NEXT' button to move on to the next step. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 99 17) To delete the added Action, click the trash can icon on the right 18) When you have completed the Action setup, click the 'NEXT' button to move on to the next step. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 100 19) Check the settings in Summary. 20) After completing the review, click the 'APPLY' button to create the r ule. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 101: Counting
5) If you press the CSV button, you can download the searched contents in CSV file format. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 102: Report
1.1) Hourly: Automatically receive data every hour, 1.2) Daily : If you specify the desired time zone, data is automatically received at the set time zone every day. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 103 Select FTP as Recipient, check FTP address, FTP Port, Passive Mode in Host, FT P user, FTP password, FTP directory path to receive, File Prefix information a nd apply. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 105 3) Add a schedule to specify when to reset the counter during the day. 4) Press the Apply button to create the counter. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 106 ● This is an additional zone setting screen. 1) Select the video source. 2) Select the detection target. 3) Enter the name of the area. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 107 3) Possible to print the counter statistics by pressing the Statistics butt 4) Possible to modify or delete the counter by pressing the Edit and Delete button. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 108 5) Possible to filter only 5 days a week. 6) Possible to respond to the request in JSON format and download it in CSV format. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 109: Search
You can search or download the action events that occurred in 'Action Rules' o f the 'AI Security' menu in CSV format. ● System Log HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 110: Display
You can search and download the necessary system logs such as user login or system startup etc. in CSV format. 2. Display ● OSD HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 111 4) Confidence Score/Tracking ID: used for AI debugging. 5) Trigger Zone: Determining whether the trigger rule display line or fig ure is displayed on the screen. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 113: System
It is possible to make settings for that streaming quality. 3. System ● License key HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 114 You can find the model name, firmware version, MAC address and etc. ● API documentation API document is embedded to work with AI BOX. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 115: Face Recognition
1. Face recognition license required To use the face recognition function, you need to purchase FR chip separately. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 116 4) The lower the camera height, the higher the accuracy (closer to the heig ht of the object). HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 117 Set the AI algorithm to Face Recognition in the Video Source menu under AI Sou rce. AI source -> Set AI Algorithm to Face Recognition in the Video source menu. AI Trigger setting HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 118 Group comparison: Compare people registered in the selected group to t rigger the appropriate person. Face Attribute Filtering: It triggers by filtering the age or gender b y the result of face analysis. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 119 ‘Face Detection’ menu under ‘AI Sources’. AI source -> Face recognition -> It is possible to create a group of face reco gnition databases from the Group menu. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 120 Click the Webcam button to allow you to directly register photos taken with th e Webcam connected to your computer to AI BOX. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 121 MyFaces / VIP / Tom.jpg The folder in the selected folder is the group name and the file name is the u ser name of the face. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 122: License Plate Recognition
2. Note of installing the camera for License Plate Recognition License plate recognition requires a separate license. The license plate recog nition algorithm is activated when you purchase the license. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 123 Same as license plate height / 10.3mm lens c. Analysis completion point / Analysis start point / Unanalyzed interval d. About 4~5m / About 20m HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 124 Same as license plate height / 2.4mm lens c. Analysis completion point / Analysis start point / Unanalyzed interval d. About 1m / About 5m 3. License plate recognition algorithm HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 125 'AI Source'. AI source -> Video source -> Set AI Algorithm to LPR in the Video source menu. 4. Create License Plate Recognition Trigger HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 126 Create a license plate recognition trigger from the ‘AI Triggers’ menu under ‘AI Security’. HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
Page 127 2) Select the Video source 3) Draw the AREA BOX where the license plate is the largest (the closer the camera is, the larger the license plate). HQ +1 (919) 230-8700 | WEST COAST +1 (310) 222-8600 ganzsecurity.com ©2020 CBC AMERICAS All Rights Reserved...
