DI-28 SERIES OPERATING MANUAL SECTION INDEX PAGE NUMBER 1.0. GENERAL 1.1. Description 2.0. SPECIFICATIONS 2.1. Platforms & Capacities 2.2. Technical 3.0. INSTALLATION 3.1. Unpacking 3.2. Inspection 3.3. Repackaging 3.4. Mini Grand Unlocking Procedure 3.5. Mini Grand Assembly 4.0. ELECTRICAL TEST 4.1. -
Page 4: General
DI-28 OPERATING MANUAL 1.0. GENERAL 1.1. Features The DI-28 Indicator offers a practical solution to a wide range of weighing applications. There are a variety of weight capacities and increments available. The display resolution is selectable from 1/2000 to 1/7500. It features RS-232 & 4 Setpoint outputs (factory options) and keyboard calibration with auto-span. -
Page 5: Specifications
2.0. SPECIFICATIONS This section includes a detailed listing of all pertinent specifications and parameters for each of the DI-28 weighing scales. The system weighing accuracy is 0.02 % for all models and they meet or exceed the requirements of OIML Class III and NIST Handbook, Number 44. Platforms The following is a list of platforms : Model... -
Page 6: Technical
2.2. SPECIFICATIONS Technical 2.2.1. Id Plate : Model # DI-28 Serial # Power Dissipation .3w Voltage Battery size C 6x1.5v or 12v AC Adapter 2.2.2. Operating Conditions : Power source : AC/DC adapter (12V, Digi Model PS-100 only, See 2.2.4. below) or 6x 1.5V size C battery, alkaline or rechargeable. -
Page 7: Installation
3.0. INSTALLATION This section provides the information required for installation of the DI-28 weight indicator. The following steps accomplish installation. Unpacking Set-up Procedure 3.1. Unpacking Each component of the DI-28 is packed in a specially designed carton. Remove each component from the carton, separate the component from its polystyrene shell assembly and set aside. - Page 8 3.4.1. Unlocking Procedure...
- Page 9 3.4.2. Unlocking Procedure...
-
Page 10: Mini Grand Assembly
3.5.1. Mini Grand Assembly... - Page 11 3.5.2. DI-28 Adapter Plate...
-
Page 12: Electrical Test
4.0. ELECTRICAL TEST 4.1. Set-up Procedure This part of the procedure is used to verify proper operation of the scale. Connect the AC power source, and press the [ON/OFF] key. At turn-on, the display will momentarily show the version number then, all digits from 0 to 9 in a “count-up” mode. Then the display will blank, show all “8’s”, and enter the regular operating display. -
Page 13: Control Panel
4.3. Control Panels 4.3.1. Keys Name Functions ON/OFF Turn power on or off. REZERO Reset the weight to zero. TARE Enter or clear tare value. DIGIT SELECT Select the digits to set tare or setpoint value. INCREASE Increase the value of tare or setpoint weight on selected digit when setting data. -
Page 14: Operation Procedure
5. Operation Procedure 5.1 Power On KEY OPERATION DISPLAY REMARKS PROCEDURE Connect DI-28 to power supply. Ver0.01 Show Software Version Make sure nothing is on the platform, and press [ON/OFF] key. 000000 Segment check starts. 888888 Ready for weighing 0.000 5.2 Tare Subtraction 5.2a One touch tare PROCEDURE... -
Page 15: Setpoint Value Entry
5.4 Setpoint Value Entry KEY OPERATION DISPLAY INDICATOR PROCEDURE ♦ Stand-by status 0.000 Enter the setpoint entry mode by 00.000 pressing [ ] three times while pressing [RE-ZERO] key. 01.000 Enter Setpoint 1 value by using [ ] and [ ] keys. -
Page 16: Programming
6.0. PROGRAM MODE 6.1. DI-28 Key Function Summary ← ← ← ← DIGIT ↑ ↑ ↑ ↑ INCREASE REZERO TARE INTERNAL COUNT REZERO EXIT - - - - CHANGE REZERO (D D T) MODE OPERATIONAL SPECS STORE & EXIT INPUT 0 INPUT 1 REZRO (D D D) INCREMENT... -
Page 17: Set Up And Calibration
6.3. Set Up And Calibration 6.3.1. Specification Change Function key for spec. change. Accessing Operational Specs. (50 - 59) 1. Press and hold down the [REZERO] key. 2. While holding , press the [← ← ← ← DIGIT] key three times . 3. - Page 18 6.4. Di - 28 Specification List 6.4.1. DI - 28 W & M Specs. W & M SPECS. PRESS AND HOLD REZERO THEN PRESS (D - T - D) Spc. No. BIT 3 BIT 2 BIT 1 BIT 0 Spec. 00 Not Used Spec.
-
Page 19: Specification List
6.4. DI - 28 Specification List (Continued) 6.4.2. DI - 28 Operational Specs. OPERATIONAL SPECS. PRESS AND HOLD REZERO THEN PRESS (D - D - D) Spc. No. BIT 3 BIT 2 BIT 1 BIT 0 Spec. 50 Sleep Timer 0000 = None 0100 = 4 Min. -
Page 20: Span Enable Switch
6.5.2. Calibration Procedure PROCEDURE KEY OPERATION DISPLAY Remarks [REZERO] [← ← ← ← DIGIT] 1. Enter calibration mode. 888888 Press and hold [REZERO] key [TARE] [TARE] while pressing [DIGIT], [TARE], [TARE] then release [REZERO] key. [↑ ↑ ↑ ↑ INCR] Press [↑... -
Page 21: Options
7.0. OPTIONS 7.1. Battery Options The DI-28 may be used with an A/C adapter or with batteries for portable operation. The indicator requires 6 x 1.5V size C battery. Alkaline or rechargeable batteries may be used. There is a built in charging circuit controlled by a jumper JP-2, which is located on the main board near the power connector. - Page 22 Options (continued) Interface 7.2. SETPOINT Interface 4 setpoint signal can be output though Setpoint connector Method: 24V Open Drain CMOS 4 Setpoint Signal Output 7.3. Hardware Options 7.3.1. 1. Pole set for DI-10/28 series Standard pole used with DIGI Platform Scales.
-
Page 23: Set Point Output, & Setpoint Wiring
Options (continued) 7.2.1 Set Point Connection 7.2.1.1. Connector Configuration Set point * When Pin 8 of CN 2 *Vcc on the main board is 1 & 2 shorted to Vcc. 8 Pin DIN Plug ( Front view ) An external voltage is needed to drive the devices like relays or LEDs. The external voltage can go up to a max. 30V DC depending on the device requirements, or a Vcc voltage, 5V DC, can be used on PIN 8 as an external voltage. - Page 24 Options (continued) 7.4.1 RS232C Connection 7.4.1.1. Wire Configuration 9 PIN D-SUB (FEMALE) 8 PIN MINI DIN (MALE) DI 28 Signal Signal 25 PIN D-SUB (FEMALE) 8 PIN MINI DIN (MALE) DI 28 Signal Signal 7.4.2. RS232C Configuration Baud rate 1200 / 2400 / 4800 / 9600 /19200 bps Data bit 7 bits or 8 bits Parity bit...
- Page 25 Options (continued) 7.4.3. Spec Setting SPEC 52 Bit 2 Send STX before text SPEC 52 Bit 3 Handshaking for RS232 output SPEC 53 Bit 0 Send Header as text SPEC 53 Bit 1 RS232C data sending method Send immediately After data is stable SPEC 53 Bit 2 RS232 data format Without header...
- Page 26 Options (continued) 7.4.4. RS-232 Communication Protocols 7.4.4.1. Text Format STX* Stable flag CR *Header Net weight CR *Header Tare weight CR LF * Options set in Spec. Stable Flag * Header (Send as code or text depend on SPEC 53 bit 0) Stable flag Data Header...
- Page 27 Options (continued) 7.4.5. Communication Method There are three methods of sending the data : Stream - Send the data immediately Manual - Send the data when [↑] is pressed using handshaking or no handshaking protocol. iii) Command - Send data when ACK code is received from remote system using handshaking or no handshaking protocol.
- Page 28 Options (continued) With handshaking (SPEC 52 bit 3 is 1) Press [↑] key to send data PC / DP - 122 DI - 28 NO RESP. Error TEXT NO RESP. Error Normal end Response time out When error Weight stable time out Weight unstable after time out iii) Command Method (SPEC 59 Bit 3 is 1)
- Page 29 Options (continued) With handshaking (SPEC 52 bit 3 is 1) PC / DP 122 DI - 28 NO RESP. Error TEXT NO RESP. Error Normal end Response time out When error Weight stable time out Weight unstable after time out...
-
Page 30: Maintenance, Calibration, Test Procedure, Service
8.0. MAINTENANCE, CALIBRATION, TEST PROCEDURE & SERVICE This section contains information and instructions concerning maintenance of the DI-28 weighing indicator. Preventive maintenance consists of periodically cleaning the external surfaces of the instrument and should be performed as often as operating conditions warrant. The calibration procedure is designed to be an aid in maintaining the scale accuracy within specifications. -
Page 31: Service & Repair
8.1.3 Continued Accuracy Weighing: The scale weighing accuracy can be determined by applying various known weights to the platform. Because of the scale's very high accuracy, only weights that are certifiably more accurate than the scale's specifications should be used in testing for accuracy. (NBS class "F" or higher) Since the scale owner does not normally have such certifiable weights available to him, it is suggested that the customer call their authorized... -
Page 32: Limited Warranty
DI-28 Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for one year.
