    All manuals and user guides at all-guides.com DI-10 OPERATION MANUAL SECTION CONTENTS PAGE NUMBER 1.0. GENERAL 1.1. DESCRIPTION 1.2. APPEARANCE 1.3. DISPLAY & KEYS 1.4. INDICATOR LAMPS 2.0. INSTALLATION 2.1. UNPACKING 2.2. INSPECTING 2.3. REPACKAGING 2.4. UNLOCKING (DIGI GRAND) 2.5. DI-10 POLE ASSEMBLY 3.0.

  • Page 3: Operation Manual

    All manuals and user guides at all-guides.com DI-10 OPERATING MANUAL 1.0. GENERAL 1.1. DESCRIPTION The DI-10 Indicator offers a practical solution to a wide range of weighing applications. There are a variety of weight capacities and increments available. The display resolution is selectable from 1/3000 to 1/10000.
  • Page 4 All manuals and user guides at all-guides.com...
  • Page 5 All manuals and user guides at all-guides.com...
  • Page 6 All manuals and user guides at all-guides.com...

  • Page 7: Installation

    All manuals and user guides at all-guides.com 2.0. INSTALLATION This section provides the information required for installation of the DI-10 weight indicator. The following steps accomplish installation. Unpacking Set-up Procedure 2.1. Unpacking Each component of the DI-10 is packed in a specially designed carton. Remove each component from its carton, separate the component from its polystyrene shell assembly and set aside.
  • Page 8 All manuals and user guides at all-guides.com...
  • Page 9 All manuals and user guides at all-guides.com...
  • Page 10 All manuals and user guides at all-guides.com...

  • Page 11: Specifications

    All manuals and user guides at all-guides.com 3.0. SPECIFICATION 3.1. PLATFORMS The following is a list of platforms : Model Platform Capacities Size/Platter S-AL bench 12” x 14” x3” 1 LB. 5 LB. 10 LB. 25 LB. 50 LB. S-SL bench / floor 13”...
  • Page 12 All manuals and user guides at all-guides.com 3.2. TECHNICAL (MODEL SPEC) * Power source * D.C 12V 0.5A (AC/DC adaptor) * D.C 1.5V x 6 pcs. (“C” cell) (“C” cell can't operate printer) * Operating temperature * -10 ... +40EC * Operating humidity * 15 ...
  • Page 13 All manuals and user guides at all-guides.com...
  • Page 14 All manuals and user guides at all-guides.com...

  • Page 15: Features

    All manuals and user guides at all-guides.com 3.4. FEATURES 1. Super Large LCD And * 25.4 mm figure height. Dynamic Filling In Graphic * 2 kinds of filling in graphic, rough and fine.(selectable) Display. * 9 kinds of weighing sign and 5 kinds of weighing unit. 2.

  • Page 16: Counting

    All manuals and user guides at all-guides.com FEATURES (continued) 14. Setpoint Data Output. * To drive external device. (Option) 15. Built In Printer. (Option) * To print out weighing result. In The Case Of Battery Drive, Printer Option Is Not Available 16.
  • Page 17 All manuals and user guides at all-guides.com...
  • Page 18 All manuals and user guides at all-guides.com...
  • Page 19 All manuals and user guides at all-guides.com...
  • Page 20 All manuals and user guides at all-guides.com...
  • Page 21 All manuals and user guides at all-guides.com...
  • Page 22 All manuals and user guides at all-guides.com...
  • Page 23 All manuals and user guides at all-guides.com...
  • Page 24 All manuals and user guides at all-guides.com...
  • Page 25 All manuals and user guides at all-guides.com...
  • Page 26 All manuals and user guides at all-guides.com...
  • Page 27 All manuals and user guides at all-guides.com...
  • Page 28 All manuals and user guides at all-guides.com...
  • Page 29 All manuals and user guides at all-guides.com...
  • Page 30 All manuals and user guides at all-guides.com...

  • Page 31: Ac/Dc Adaptor

    All manuals and user guides at all-guides.com 5.3. RS-232 (continued) 2. Communication Control Command. DC1 (11H) : Data request from DI-10. DC3 (13H) : Communication break request. (DI-10 receives “DC3”, the time out will be extended to 5 sec. ACK (06H) : Positive response. NAK (15H) : Negative response.

  • Page 32: Maintenance, Calibration, Test Procedure & Service

    All manuals and user guides at all-guides.com 6.0. MAINTENANCE, CALIBRATION, TEST PROCEDURE & SERVICE This section contains information and instructions concerning maintenance of the DI-10 weighing Scale. Preventive maintenance consists of periodically cleaning the external surfaces of the instrument and should be performed as often as operating conditions warrant. The calibration procedure is designed to be an aid in maintaining the scale accuracy within specifications.
  • Page 33 All manuals and user guides at all-guides.com...

  • Page 34: Error Message List

    All manuals and user guides at all-guides.com 6.4. ERROR MESSAGE LIST The following error messages will appear when an incorrect operation is taken : Add OF Whwn accumulated weight total exceeds 6 digits. When quantity displayed exceeds 6 digits. When displayed weight exceeds scale capacity. Spn Er When weight value entered during calibration procedure is not in proper range .
  • Page 35 All manuals and user guides at all-guides.com...

  • Page 36: Spec. List

    All manuals and user guides at all-guides.com 6.5.2 SPEC. LIST Function Table Of 141 SPEC # Bit 3 Bit 2 Bit 1 Bit 0 & standard setting Spec 00 not used Setpoint Function Negative Wt. Acc. Printer Connection 0 = yes 0 = yes 0 = no 0 0 0 0...
  • Page 37 All manuals and user guides at all-guides.com 6.5.3 SPEC.LIST (continued) Function Table Of 142 SPEC # Bit 3 Bit 2 Bit 1 Bit 0 & standard setting Spec 13 Zero Tracking Re-Zero Key Scale Start Range Weighing Unit 0 0 0 0 During Tare During Tare (Display/Print)
  • Page 38 All manuals and user guides at all-guides.com...
  • Page 39 All manuals and user guides at all-guides.com...

  • Page 40: Notes

    All manuals and user guides at all-guides.com NOTES:...
  • Page 41 All manuals and user guides at all-guides.com DI-10 Limited Warranty Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and systems properly installed by a Distributor or Original Equipment Manufacturer (OEM) will operate per written specifications as confirmed by the Distributor/OEM and accepted by RLWS. All systems and components are warranted against defects in materials and workmanship for one (1) year.
