- Page 1 INSTRUCTION...
- Page 2 P ART L IST PART NO: DESCRIPTION Q’TY Bottom tube Upright pos t Support tube Adjustable extension tube Arm curl tube Foam tube U shape tube Back rest tube Back rest Arm curl PVC cap End cap φ50 Oute r bushing slee ve 50*45 Release k nob Foam End capφ25...
- Page 3 STEP 1 Insert the end caps (12) into the front & rear tubes (1)，then assemble (2) to (1) and screw it b y（ 19， 20， 21） ; Insert (31) into (3) and assemble the caps (12) to (3) and attach (3) to (2) fix ed b y (24, 20, 21), finall y insert 28，...
- Page 4 STEP 2 1. Insert (18) to (8), connect (8) by (27, 20, 21) to (3), then fix (7) to (8) by (27, 20, 21); Connecting (3) and (7) by (17), and fix (9) to (8) by (22, 23), see above picture. 2.
- Page 5 GARLANDO SPA Via Regione Piemonte, 32 - Zona Industriale D1 15068 - Pozzolo Formigaro (AL) - Italy www.toorx.it - info@toorx.it...
