Application Notes

Outputs

There are defined Function Outputs where functions
correspond to the output name and Spare Outputs that
will be assigned functions through the IntelliLink Setup
Software. See S&C Instruction Sheet 766-530 for the
available settings.
Each output has a normally open contact and a
normally closed contact. When the designated function is
active, the contact states will change until that function
is deactivated.
Table 5. Defined Function Outputs
Input Name
This output will activate when the connection to the control has been lost or the control is in an Error state indicating
Error
that operations through the external interface are not possible .
Only three-phase indication is provided . When there is a Pole Mismatch state, the indication is "Closed ."
Open
Only when all three poles are open will the indication be "Open ."
Close Only three-phase indication is provided . When there is a Pole Mismatch state, the indication is "Closed ."
Only when all three poles are open will the indication be "Open ."
Ground Trip Block This is active when the Ground Trip Block function is applied . See S&C Instruction Sheet 766-530 for
configuration options .
Hot Line Tag This is active when the Hot Line Tag function is applied . See S&C Instruction Sheet 766-530 for Hot Line Tag
protection profile options .
Spare OUT1 These options will be provided in a future firmware version . See S&C Instruction Sheet 766-530 for configuration
options .
Spare OUT2 Same as OUT1 .
Spare OUT3 Same as OUT1 .
Spare OUT4 Same as OUT1 .
14 S&C Instruction Sheet 766-514
