USER SETTING

WARNING AND ERROR MESSAGES

In the event of an error, the charger will display a message and a beep sound.
1. " BATTERY CONNECTOR" : Connection problem, check that the cable is well connected
to the charger or that it is not defective (damaged, not correctly soldered).
2. " INPUT VOLTAGE FLUCTUATION" : Input voltage variation greater than 1V, please check
the input power to ensure that the input voltage variation range does not exceed the
normal allowed range.
3. " BATTERY VOL ERR - CELL CONNECT" : Total battery voltage (V) error, check the voltage
(V) of each battery cell.
4. " TEMP OVER ERR" : The temperature of the charger is too high, please cool it down.
5. " SHORT CIRCUIT ERROR" : Short circuit; please check all charging cables and connec-
tors.
6. " CAP OUT" : Charger capacity protection value higher than the set value, check and
reset the capacity protection value. Capacity Cutt-Off Program
7. " INPUT VOLTAGE ERROR" : Input voltage (V) error, check the input power.
8. " REVERSE POLARITY" : Incorrect battery connection polarity, reverse the polarity of the
connected battery.
9. "SAFETY TIME OUT" : Reset the security timer.
Firmware Update
Press ENTER to update the firmware.
Power distribution
When using AC power, you can choose between intelligent or
average distribution mode.
