R&G FI0094BK Fitting Instructions

Frame insert for bmw s1000rr 2015- left hand side

FITTING INSTRUCTIONS FOR FI0094BK FRAME INSERT

BMW S1000RR 2015- LEFT HAND SIDE

THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.

DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.

Please note that the way the kit is packed does not necessarily represent the way of

HE PARTS SHOWN MAY BE REPRESENTATIVE ONLY

M5x30mm LONG COUNTER SUNK BOLT (x1)

BUBBLE

STICKERS

(x4)

Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire, GU34 3AQ

Tel: +44 (0) 1420 89007 | Fax : +44 (0) 1420 87301 | Email: info@rg-racing.com

mounting to the bike

(

FOR CLARITY OF INSTRUCTIONS ONLY

R&G Racing

)

FRAME INSERT (FI0094) (x1)

SPECIAL

NUT

(H0035) (x1)
