COMMAND 46 - Trim DAC Gain

Description
This command calibrates the device Digital to analog converter gain. This is done by
writing the same current value that is measured in the loop.
Write Parameters
Word High Byte
0 Floating Point Measured Current (mA)
1
Floating Point Data Returned
Word High Byte
0 Floating Point Current (mA)
1
Integer Data Returned
Word High Byte
0 STATUS WORD
Page 144 of 171
MVI56-HART ♦ ControlLogix Platform
HART Multi-drop Master Communication Module
Low Byte
Low Byte
Low Byte
