4. Internal Delay Selection Switches
Four internal DIL switches are available to select 8
time delay settings as shown below.
Please Note: On the DIL switch, switch 1 is not in use
ON
2 mins 5 mins 10 mins 30 mins 60 mins 90 mins 120 mins 180 mins
Time (minutes) Switch 4 Switch 3 Switch 2
6
Left = ON
ON ON
2
5
10
30
60
90
120
180
Right = OFF
ON ON
L
L
L
L
R
R
R
R
ON ON
L L
L R
R L
R R
L L
L R
R L
R R
ON
