L -
SL - MAINS LIVE OUT (TO EXTERNAL LOAD)
N – NEUTRAL (IN) (fourth from right hand position
N – NEUTRAL (OUT) (fifth from right hand position
• NOTE: Ensure that all screws on the mains
connector are tightened adequately.
• Adequately tighten the nuts on the cable entry
5
points on the outside of the box.
• Select the required time delay by using the time
delay selector as shown below.
• Screw the front panel back on. Ensure tight fitting
for IP compliance
• Switch on mains supply. The unit is now ready for
operation.
MAINS LIVE IN (right hand position of
connector)
(second from right hand position of connector)
EARTH – Connect any Earth wires to this pin
of connector)
of connector)
