Appendix 1: Resistance Table of Ambient Temperature Sensor for Indoor and Outdoor Units(15K)

Temp. Resistance kΩ
-19 138.1
-18 128.6
-17 121.6
-16 115
-15 108.7
-14 102.9
-13 97.4
-12 92.22
-11 87.35
-10 82.75
-9 78.43
-8 74.35
-7 70.5
-6 66.88
-5 63.46
-4 60.23
-3 57.18
-2 54.31
-1 51.59
0 49.02
1 46.6
2 44.31
3 42.14
4 40.09
5 38.15
6 36.32
7 34.58
8 32.94
9 31.38
10 29.9
11 28.51
12 27.18
13 25.92
14 24.73
15 23.6
16 22.53
17 21.51
18 20.54
19 19.63
Temp. Resistance kΩ
20 18.75
21 17.93
22 17.14
23 16.39
24 15.68
25 15
26 14.36
27 13.74
28 13.16
29 12.6
30 12.07
31 11.57
32 11.09
33 10.63
34 10.2
35 9.779
36 9.382
37 9.003
38 8.642
39 8.297
40 7.967
41 7.653
42 7.352
43 7.065
44 6.791
45 6.529
46 6.278
47 6.038
48 5.809
49 5.589
50 5.379
51 5.197
52 4.986
53 4.802
54 4.625
55 4.456
56 4.294
57 4.139
58 3.99
Temp. Resistance kΩ
59 3.848
60 3.711
61 3.579
62 3.454
63 3.333
64 3.217
65 3.105
66 2.998
67 2.896
68 2.797
69 2.702
70 2.611
71 2.523
72 2.439
73 2.358
74 2.28
75 2.206
76 2.133
77 2.064
78 1.997
79 1.933
80 1.871
81 1.811
82 1.754
83 1.699
84 1.645
85 1.594
86 1.544
87 1.497
88 1.451
89 1.408
90 1.363
91 1.322
92 1.282
93 1.244
94 1.207
95 1.171
96 1.136
97 1.103
Temp. Resistance kΩ
98 1.071
99 1.039
100 1.009
101 0.98
102 0.952
103 0.925
104 0.898
105 0.873
106 0.848
107 0.825
108 0.802
109 0.779
110 0.758
111 0.737
112 0.717
113 0.697
114 0.678
115 0.66
116 0.642
117 0.625
118 0.608
119 0.592
120 0.577
121 0.561
122 0.547
123 0.532
124 0.519
125 0.505
126 0.492
127 0.48
128 0.467
129 0.456
130 0.444
131 0.433
132 0.422
133 0.412
134 0.401
135 0.391
136 0.382
