Page 12
Use the voltage specified on this unit Only. Using this unit with a higher voltage than specified is dangerous and may cause fire , damage to this unit, or personal injury. SMSL will not be held responsible for any damage resulting from the use of this unit with a voltage other than that specified.
Page 13
Sanskrit 10th Features Ultra-tiny shape design and supports a variety of placement ways ; The second-generation XMOS solution supports sampling rate up to 32bit/768KHz and DSD512 ; Two pieces of Japanese ultra-low phase noise clocks, greatly reducing the system JITTER ;...
Sanskrit 10th Specifications Input ...................USB / Optical / Coaxial Output Level.....................2.2Vrms THD+N ......................0.0002% Dynamic range ....................118dB SNR ........................120dB USB compatibility ..............Windows 7 / 8 / 8.1 / 10 Mac OS X10.6 or Later / Linux Bit depth USB ......................1bit ~ 32bit Optical/coaxial ..................16bit ~ 24bit...
Approximately 8 m(26 ft) Display ON/OFF Input switch Sanskrit 10th Switch to control Do not press for this unit Note 1. This remote controller use 2 x R03/AAA batteries. 2. When you first operate Sanskrit 10th, press the C key first.
Sanskrit 10th Parts Introduction Remote Window Display POWER/INPUT KEY Audio Outputs Coaxial Input Optical Input USB Input Aux Power Supply (see Note) Note: 1. This is the Aux power input, when you use phones to connect the USB, you need to connect a 5V DC power for avoiding the phone overcurrent ;...
Page 17
Note: Sanskrit 10th must be placed horizontally, otherwise the display may not work properly! 3. TURN OFF THE DISPLAY The Sanskrit 10th can be turned off the display for you to enjoy the music without light interfere. 1 ) Use the “FN” key of remote controller to switch on or off this function.
Instructions 4. DISPLAY INSTRUCTIONS 1 ) When starting up the unit, it will display , which stands for Sanskrit 10th. 2 ) When starting up the unit, it will display 2 seconds of , volume and current sampling rate in turn.
Page 19
Placement during calibration(button on the right side) 2. Calibrating gravity sensor Put Sanskrit 10th in the horizontal position, which means, the power button is on the right side, and the unit is in the standby state; Press and hold the power button for 5 seconds, the display will show “CAL”, at this time, the system will start automatic calibration;...
Sanskrit 10th Warranty Terms 1.The Term of Service Foshan Shuangmusanlin Technology Co., Ltd promises to offer good-quality products. If the product is broken in 7 days after purchasing when you use it normally, you can choose to send it back for return, replacement or repairing (only the product does not affect the second sales can be returned ).
