USER MANUAL
http://www.smsl-audio.com/

Advertisement

Table of Contents
loading

Related Manuals for SMSL M500

Summary of Contents for SMSL M500

  • Page 1 USER MANUAL http://www.smsl-audio.com/...

  • Page 2: Safety Notes

    Safety Notes Install this unit in a well ventilated, cool, dry, clean place-away from direct sunlight, heat sources, vibration, dust, moisture, or cold.. Use the voltage specified on this unit Only. Using this unit with a higher voltage than specified is dangerous and may cause fire , damage to this unit, or personal injury. Our company will not be held responsible for any damage resulting from the use of this unit with a voltage other than that specified.
  • Page 3 Features Supports MQA decoding; The top performance D/A chip ES9038PRO from ESS Technology; The high-performance power supply chip ES9311, the noise of ES9311 is as low as 1uVrms, to push ES9038PRO to the limit; XMOS XU-208, true 32bit audio processing, supports DoP and Native DSD, and reaches 32bit/768kHz and DSD512;...

  • Page 4: Specifications

    44.1 ~ 768kHz DSD 2.8224 ~ 22.5792MHz Optical / Coaxial 44.1 ~ 192kHz DSD64(DoP) Headphone amplifier output power ........... 570mW(32Ω) 290mW(64Ω) 125mW(150Ω) 65mW(300Ω) ..................5W Power Consumption ................... <0.5W Standby power 85x88x197mm (WxHxD) ..............Size .....................0.91kg Weight Note Firmware and driver download: http://www.smsl-audio.com/cn/download.asp...

  • Page 5: Remote Control

    Power ON/OFF Mute Volume MENU/OK Next level menu Return Volume /down Output select Input select Switch to control M500 Invalid Note 1. This remote controller use 2 x R03/AAA battaries. 2. When you first operate M500, press the C key first.
  • Page 6 Display Interface and Instructions (+)HOT — ( )COLD Display Remote window Knob* 6.35mm headphone jack Balanced output RCA output Optical 1 input USB input AC IN Optical 2 input Power switch Coaxial input * Note: Knob 1. Konb: Volume/Menu up or down 2.

  • Page 7: User Interface

    User Interface 1. Main 384kHz 1、Output indicator Line out， Headphones out 2、Volume Level 3、Input source 4、Stream indicator 5、Audio format indicator* 6、Current Sample rate (Display "NO SIGNAL" when unlock or no connection, or display "MUTING" when it is muting) *Note： When the PCM audio is 88.2 kHz or even more, it will display" ".
  • Page 8 MQA audio, it is suggested to adjust the volume of the computer to the maximum for the best audio output. The M500 LED next to MQA logo glows green or blue to indicate that the unit is decoding and playing an MQA stream or file, and denotes provenance to ensure that the sound is identical to that of the source material.

  • Page 9: Factory Reset

    Setting 2. SETUP MENU 1. INPUT SETUP MENU INPU T OPTI 1 OUTPUT OPTI 2 FILTER COAX DIMMER 2. OUTPUT SYSTEM LINE OUT HP OUT *Note:The output of circuit is both RCA and SLR output. 3. FILTER (This setup is only valid for non-MQA PCM format. Products with a full MQA Decoder unfold the file to deliver the highest Fast Linear possible sound quality.
