Introduction to Curiosity High Pin Count (HPC)
FIGURE 1-1:
HPC DEVELOPMENT BOARD REV 1
3
2
1
1. USB micro connector
2. 3.3/5V power jumper
3. Master Clear Reset button
4. Dual-row expansion headers
5. PIC MCU socket for 28-pin microcontroller
6. PIC MCU socket for 40-pin microcontroller
7. mikroBUS
Click Board socket 1
8. mikroBUS
Click Board socket 2
9. Push button SW2
10. Push button SW1
11. Potentiometer
2016-2020 Microchip Technology Inc.
4
5
6
11
4
10
7
9
8
DS40001856C-page 9
