- Page 1 Horizontal Anchorage System System AW1 Original installation manual This manual must be readily available to assembly staff at all times. Other copies can be obtained on request. www.tractel.com...
-
Page 2: Table Of Contents
Notes on this installation manual Date of issue Manufacturer's address TRACTEL Greifzug GmbH April 2013 Scheidtbachstrasse 19-21 51469 Bergisch Gladbach Copyright Postfach 20 04 40 The copyright of this operating manual remains with 51434 Bergisch Gladbach TRACTEL Greifzug GmbH. Tel:... - Page 3 7. Rescue ..............................15 8. Use, misuse and handling 11.1 Authorized use........................15 11.2 Predictable misuse or handling ....................15 10. Transport and storage of the anchorage system ..............15 11. Servicing and troubleshooting. 12. Ordering spare parts ........................15 Issued 04/13 Original installation manual Anchorage System AW1 Page 3 of 16...
-
Page 4: Defi Nitions And Symbols Used
1. Defi nitions and symbols used 1.1 Defi nitions The terms used in this manual have the following meanings: "Anchorage system": Safety equipment "Qualifi ed person": An authorized specialist is considered to be someone who has undergone specialist training and has sufficient knowledge in the field of anchorage systems and is familiar with the relevant government industrial safety and accident prevention regulations, directives and the recognized technical regulations of other EU member statesto the degree that they are capable of evaluating the safe working condition and proper application of anchorage systems (BGG 906) -
Page 5: Safety Instructions
1.3 Safety instructions Danger Death, severe or minor injuries caused by incorrect handling ➜ Observe the details in this manual a) Only those personnel that are familiar with the assembly and / or operation of the anchorage l) If faults or damages are found during operation or any system and its suspension should be assigned. -
Page 6: Presentation
2. Presentation Fig. 1 Guide rail 2.1 Delivery state and scope of the anchorage system 2.1.1 Delivery state of the anchorage system The anchorage system is supplied disassembled. Fig. 2 Joint connector 2.1.2 Scope of delivery The following accessories are not included in the scope of supply: –... -
Page 7: Limits Of The Anchorage System
Moreover, the regulations and legal guidelines as stated in 2.3.3 apply. Other national regulations must be observed. 2.3.2 Maintenance and inspection Only persons authorized by TRACTEL Greifzug GmbH are allowed to perform maintenance and inspection on the anchorage system (see defi nition and chapter 10). 2.3.3 Legal requirements... -
Page 8: System Design Assembly On The Side Or Suspended
3. Components 3.1 System design 3.1.1 System design assembly on the side or suspended (Fig. 7) 3.1.2 System design (custom production) suspended assembly (Fig. 8) Fig. 7 Fig. 8 max. 1,500 mm Guide rail Support bracket for guide rail on the subsurface Catch Joint connector I-120 sub-construction... -
Page 9: Guide Rail
3.2 Components Fig. 9 3.2.1 Guide rail The guide rail (Fig. 9) is used for mounting the anchorage device W3. Length: 1,000 mm – 6,000 mm Weight depending on the length: 3.8 kg – 22.7 kg Material: steel, hot-galvanized or INOX 1.4571 Fig. -
Page 10: Catches
3.2.4 Catches The catches (Fig. 12 a – b) prevent the anchorage Fig. 12 a Fig. 12 b device running out of the system unintentionally. The fi xed catch (Fig. 12a) is installed fi xed. The anchorage device cannot be removed. Kit: Length of pipe, screw M 8, self-locking nut Weight: 0.1 kg Fig. -
Page 11: Technical Data And Weights
3.3 Technical data and weights 3.3.1 General information The technical data and weights can be found in the description of the individual components. Fig. 15 3.4 Products forming part of the anchorage system 3.4.1 Anchorage device W3 The anchorage device W3 (Fig. 15) is inserted at one end of the guide rail of the system. -
Page 12: Tools And Equipment Required
6.2 Tools and equipment required Wrench M8, M10, M12 Torque wrench M8, M10, M12 up to 100Nm Measuring instrument Spirit level, tape measure or folding rule PPE against falls from a – Authorized safety harness height for fi tters – Safety rope with shock absorber –... -
Page 13: Support Bracket For Side Assembly
6.4.3 Support bracket for assembly of the guide rail on the side Fig. 17 c (Fig. 17 c) 1. The support bracket (Pos. 6) is fi xed to the concrete wall (concrete strength, min B25) using anchor fi ttings approved for use by the building authorities. -
Page 14: Fixed Catch
6.4.7 Fixed catch (Fig. 21) Fig. 21 The length of pipe for the fi xed catch (Fig. 21) is inserted into the end of the guide rail and the M8 x 80 screw is pushed through the holes in the guide rail from the outside and through the length of pipe. - Page 15 11. Ordering spare parts For ordering spare parts, please use the respective component catalogue for the anchorage system. For ordering, please contact your authorized specialist dealer or a member of the globally active Tractel Group (see last page). Issued 04/13...
- Page 16 107031 Russia Tel. +48 22 300 12 31 • Fax +48 22 300 15 59 T : 7 495 989 5135 • Fax : 7 495 589 3932 G824.2_MA_FABA_HLS.indd • 500 570 • 04/13 • © TRACTEL Greifzug GmbH 2013...
