  • Page 1 Galaxy G6 Galaxy G6 Measuring System User Manual *All Rights Reserved - 1 -...

  • Page 2: Table Of Contents

    Galaxy G6 Directory Directory............................ - 2 - ChapterⅠ Brief Introduction ....................- 4 - §1.1 Introduction ....................... - 4 - §1.2 Applications ....................... - 4 - §1.3 Main Features ......................- 4 - ChapterⅡ Hardware Component ..................... - 7 - §2.1 Mainframe .........................
  • Page 3 §7.2.5 Tilt Survey ....................- 105 - §7.2.6 Radio Router ....................- 108 - Appendix A Galaxy G6 technical specifications ..............- 109 - Appendix B GDL-20 radio technical specifications ............- 111 - Appendix C Technical Terms ....................- 113 -...

  • Page 4: Chapterⅰ Brief Introduction

    SOUTH, please visit our official website http://www.southinstrument.com/ This manual takes Galaxy G6 measuring system for example, to explain how to install, set up and uses the RTK system as well as the use of the accessories. We recommend that you read these instructions carefully before using the instrument.
  • Page 5 As the new feature and technology adopted on Galaxy G6, G6 allows users to control and configure the receiver by connecting its broadcasted wifi hotspot with any kind of mobile terminal. Also Galaxy G6 is the first to adopt WiFi as datalink that greatly improve the flexibility of actual measurement.
  • Page 6 Amazing Housing Galaxy G6, with and innovative design, built with magnesium alloy materials. And the top edge is design to decrease harm for receiver in case of fall down to ground...

  • Page 7: Chapterⅱ Hardware Component

    60mm. the body is made up of magnesium alloy material, it makes overall the G6 be more rugged and durable. Galaxy G6 adopts LCD and buttons combination design, install with an attractive OLED display that mode settings and status are intuitive to know, easy to operate.
  • Page 8 Galaxy G6 ③ Page up/down, selection button F Key ④ Power on/off receiver, confirm button Power Key ⑤ Display the working mode and status of receiver OLED Display Indicators The indicators are located at the left side of front component, details meaning please check the table below.
  • Page 9 Galaxy G6 Display and main interface Power on G6 and after initializing, it will get into the main interface and begin to search the satellite like a radar on skyplot, then you will get a voice saying the working mode, 10 seconds later the screen will automatically switch to display the coordinates and other information.

  • Page 10: Side Components

    Galaxy G6 means the receiver is establishing WiFi connection as WIFI client, and if the WIFI successfully connected the symbol will change to be ; when it shows that means the receiver is broadcasting its WIFI hotspot (We recommend to turn it off while unused.) ⑦...

  • Page 11: Bottom Components

    Galaxy G6 Component Description ① Where we can insert a SIM card when the receiver is set in SIM card slot GPRS mode ② Restore the cover after installing the battery to avoid the Battery cover battery slips off ③...

  • Page 12: Operation On Receiver

    Static Mode Setting To make a static job with Galaxy G6, first you have to set the receiver in Static mode. Get into the Mode Select page and place the select box at the Static Mode (first item), then press...
  • Page 13 Galaxy G6 What we should do in the next is setup all the parameters for static mode. Press power key once and enter Record Option page, all the parameter items are displayed here including point name, antenna height, sample interval, record mode and data type.
  • Page 14 Galaxy G6 NOTE: Please ensure the parameter values static mode are the same if there are more than 2 pcs units work at the same time. Base Mode Setting Press F key after initialization to get into configuration interface, then move select box to Mode Select option and press Power key to enter Mode Select page, move the select box to Base Mode (second item) and press Power key to confirm.
  • Page 15 Galaxy G6 Diff Type: This is the correction format which base support to transmit, there are RTD, RTCM23, RTCM30, RTCM32,CMR, SCMRX for optional. Mask Angle: It is a altitude restricted angle which is an angle defined from horizontal level to the sky direction, it is mainly used to control satellite view for GPS receiver.

  • Page 16: Datalink Setting

    §2.2.3 Datalink Setting Galaxy G6 is integrated with a series of excellent and advanced datalink modules make it be an extremely powerful system that includes built-in radio module, cellular module, Bluetooth and WIFI, G6 is not only able to connect with the external module, but also can close the datalink if it is not the necessary use.
  • Page 17 Galaxy G6 Press F key to get into main configuration interface after the initialization or the working mode has been setup, then move the select box to Set Data Link option by pressing F key, and press power key to confirm and enter the interface, there are UHF, Cellular Net, Bluetooth, Dual Transmitting, WIFI Datalink, External, Close Datalink and Main menu options displayed on this interface.
  • Page 18 Galaxy G6 Protocol: This is radio communication protocol for data transmission, SOUTH and TRIMTALK are optional in this page and SOUTH is the default setting, if it is changed, Base and Rover must use the same protocol for communication. Power: This appears only in Base mode, the radio transmitting power is allowed to define in High, Middle or Low power.
  • Page 19 Galaxy G6 Bluetooth Mode Setting This mode is used on Rover that access the reference station for corrections by using data collector internet that transfer the corrections to receiver through Bluetooth. WIFI Datalink Setting This is the pioneer to use WIFI as the datalink that connect to the internet and access to reference station for corrections.

  • Page 20: System Setting

    §2.2.4 System Setting In System Setting, you will have more configurations for Galaxy G6 that includes Language setting, Voice option, selfcheck, online service and so on. Move the select box to System Option and then enter the configuration page, there you will have Language, Voice Option, System Info, Self Check, Online Option, Other Option and Copy Static File items displayed on this page.
  • Page 21 Galaxy G6 Voice Option Users can turn on/off the voice prompt and turn up/down the volume in Voice Option page. Sytem Info Get into System Info page, more detail information about the receiver is displayed here including receiver ID (the serial number), firmware version, expired date and remaining memory...
  • Page 22 Galaxy G6 Online Option This online service option is used for registration and upgrade firmware online for Galaxy G6, it is ver convenient that ou don t need an more PC software to do this. Other Option In this page, there are USB mode, Display SV and Power items displayed.
  • Page 23 Galaxy G6 If USB Disk option is selected, then Galaxy G6 will be detected as a flash disk when connects to computer via USB cable, in this case, ou can cop the static data from G6 s memor folder. If Ethernet option is selected, G6 is equivalent to a network adapter that you can access to the internal web ui page of G6 through USB cable when connect G6 with computer.

  • Page 24: Wifi Config

    Copy Static Files Galaxy G6 is able to work as a USB OTG host that it can be connected a USB flash disk directly via an OTG cable, then users can copy the static data to USB flash disk. Set the USB mode as USB disk.
  • Page 25 Galaxy G6 IP: G6 will generate an LAN IP address for accessing its internal web UI page after connecting to the WIFI. If the WIFI working mode is selected to be AP , the WIFI hotspot information will be displayed at WIFI Info page.
  • Page 26 WIFI working mode setting For the WIFI working mode, it is not only to be the hotspot, but also to be a datalink that help Galaxy G6 to connect to internet and obtain corrections from reference station. - 26 -...

  • Page 27: Datalink Info (Only For Base/Rover)

    Galaxy G6 AP: This item means the WIFI hotspot broadcasted by G6 for mobile terminals such as smartphone or tablet to connect and access the Web UI. Client: If this item is selected, G6 will connect to the internet via WIFI connection and then download the corrections from reference station.

  • Page 28: Config Mode

    Galaxy G6 §2.2.7 Config Mode This option is mainly used to configure the modem direct connect mode for receiver debugging or problem diagnosis. UHF, Cellular Net, Sensor Config and GNSS OEM are contained in this mode. §2.2.8 Power Off To power off the receiver, move the select box to Power Off item or press power button and hold for 3 seconds, the reminding page appears with the options of Exit, OFF and RESET, select OFF button to power off the receiver or move to RESET to restart receiver.

  • Page 29: Chapterⅲ Web Ui Configuration

    Because of using the smart embedded Linux operating system and SOUTH intelligent cloud technology, Galaxy G6 is allowed to configure and monitor the status of itself in real-time on web UI. G6 supports to access its web UI via its broadcasted WIFI hotspot and USB mode.

  • Page 30: Web Ui Main Interface

    Galaxy G6 §3.2 Web UI main interface After connecting to the WIFI, input IP 10.1.1.1 into the IP address bar of IE explorer and the login page will appear. Input admin for both username and password, click Login button then all the items are displayed on Web UI home page.
  • Page 31 Galaxy G6 In the Web UI home page, Status, Configuration, Satellite Information, Data Record, Data Transfer, Network Config, Radio Config, Firmware Update, User Management and Help are listed at left side. And the positioning informaiton including positioning information and satellites are diplayed at right side.

  • Page 32: Status

    Galaxy G6 Offers solutions Help §3.2.1 Status System Information, Work Status and Position Information are listed under Status menu. System Information In this page, all the information of G6 is diplayed such as serial number, hardware ID, MAC address, firmware version and so on.

  • Page 33: Configuration

    General Config, Base Setup, Antenna Setup, Satellite Tracking, Receiver Operate and Default Language are contained under Configuration menu. Users are able to configure all kinds of parameters for Galaxy G6 under Configuration menu, and all the settings are immediate effect - 33 -...
  • Page 34 G6 for us to apply for another available code, then input the code into the blank or register the receiver online. Galaxy G6 is allowed to setup the working mode and datalink from this Web UI that only need the mobile phone or tablet PC is able to connect the wifi hotspot of G6.
  • Page 35 Galaxy G6 Work Mode: There are Rover, Base and Static contained in this dropdown list Datalink: Pull down the list, there will be all kinds of options for datalink, such as radio, Network, External, Bluetooth, WIFI and CSD. Radio Route: This feature is used to transfer the correction which from the reference station for the other rover by radio, the rovers will have the same coordindates from the reference station.
  • Page 36 Galaxy G6 RTK Record: This is used to enable raw data recording in base mode or rover mode for post-processing 1 PPS: This option is for the 1 pulse per second output EVENT: This option is for the EVENT marker input EVENT Polarity: EVENT input method.
  • Page 37 Galaxy G6 CMR ID/RTCM2.X ID/RTCM3.X ID: Users can specify the ID for transmitting correction. Position: Click this button to capture the coordinates for current position Spare: This is used to the repeat station Base Start Mode: Here contains 3 methods to start the Base, manually start base, automatically start base by fixed point, automatically start base by current point.
  • Page 38 Galaxy G6 Receiver Operate The page provides all kinds of operations to control the receiver such as self-check operation, clean epochs, factory reset, reboot and power off. Self-check: Users can also do the self-check from this configuration page, click on the Check all button to check all the modems or click on the check button corresponding to the modem to check one by one.

  • Page 39: Satellite Information

    USB: This is used to configure G6 what kind of mode output from 7-pin port when connect the receiver with computer via USB cable. USB and network port for optional. Default Language: Configure the default language for Galaxy G6. §3.2.3 Satellite Information The Satellite Information provides all kinds of tables, graph and the sk plot to view the information of tracking satellites.
  • Page 40 Galaxy G6 Tracking Chart In this page, the histogram will indicate the signals from those used satellites, and allow to check each constellation separately. Skyplot In this page, all the tracking satellires are shown on the skypolt, this let users intuitively view and know where the current position of satellite is.
  • Page 41 Galaxy G6 GPS on/off For all the running GNSS constellations or the augmentation system, G6 allows to configure to use which satellite or not. In gnss on/off page, all the running satellites are listed, and unselect the box corresponding to the satellite to not use it.

  • Page 42: Data Record

    §3.2.4 Data Record The Data Record performance is mainly used to configure all the parameters for receiver in static mode. Much more operations can be done on Galaxy G6 such as storage path, interval, data format and data files download.

  • Page 43: Data Transfer

    Galaxy G6 Data Download This page provides the data files to download Choose the storage where the static data recorded, and file type, then click on the blank of Select Date to choose what date the data was recorded and click Get Data button, all the files recorded in the date you choose will show in the table, tap download button to download the data files.
  • Page 44 Navigation Data: This is the navigation data output from receiver such as NMEA-0183, GSV, AVR, RMC and so on. It is configured in Data Flow Config page. SIC Observation Data: This is the user-defined format observation data from SOUTH. OpenSIC Observation Data: This is the open version of SOUTH user-defined format observation data for secondary development.
  • Page 45 Server: Galaxy G6 will upload the data onto internet by the static WIFI if server is selected, then users are able to obtain its dynamic data by accessing to G6 through the IP from receiver.
  • Page 46 Active: Check on this circle to activate this function. Authentication Mode: These two modes use different protocol standard for the connection, Eagle Mode is SOUTH standard mode, and TCP/IP Mode is for private network use, usually, choose the Eagle mode for the default setting.
  • Page 47 HHHH_RTCM30 NtripCaster This feature is finally realized on Galaxy G6, the receiver is equivalent to a CORS system that it generates and broadcasts the user-defined correction for rover if G6 connects a static IP address.

  • Page 48: Network Config

    Galaxy G6 Data Flow Config In this page, users can freely to configure the content and the update rate of data flow that to output or not to output what kind of data format. Click on the dropdown list for each data format to define the update rate §3.2.6 Network Config...
  • Page 49 Galaxy G6 including the hardware information and dialing status. Status: The dialing status and hardware information are displayed in this field that users can intuitively to view the signal of network, module model and the IMEI number of the module.
  • Page 50 Galaxy G6 WIFI Config This is mainly used on the WIFI configuration for Galaxy G6, there are AP mode and Client mode for optional. This is used to enable the WIFI hotspot for G6 to broadcast for mobile terminals such as smartphone or tablet to connect and access the Web UI.
  • Page 51 Galaxy G6 Client: This option enables Galaxy G6 to search and connect the other WIFI hotspot which connects to the internet, the receiver is able to download and use the mountpoint from reference station. Client_SSID: This is the WIFI hotspot which G6 is going to connect Scan: Click this button to search the surrounding available WIFI hotspot.
  • Page 52 Galaxy G6 Bluetooth Config In this page, users can view the information and connection status of Bluetooth, such the MAC of Bluetooth, discoverable or not, the PIN code, and the connection devices in following table. Port Forwarding This page is mainly used to view and configure the internet transmission port for G6, customize and debug receiver.
  • Page 53 Galaxy G6 NOTE: Usually we will keep the default setting in this page, if you would like to modify it, please contact with SOUTH technician for more supports. Router This is mainly used to view and configure the parameters for router, only under the condition of customize and debug receiver.

  • Page 54: Radio Config

    As the name implies, the parameters of radio can be done in Radio Config , it is divided into Radio Parameter and Radio Frequency. Radio Parameter This page is mainly used to configure the parameters for internal radio module of Galaxy G6. - 54 -...
  • Page 55 High, Middle or Low power. Protocol: This is radio communication protocol for data transmission, SOUTH and TRIMTALK are optional in this page and SOUTH is the default setting, if it is changed, Base and Rover must use the same protocol for communication.

  • Page 56: Firmware Update

    This page displays all the information of the firmware which current installed on G6, and allows to update the latest version firmware for receiver. To get latest version firmware please contact with SOUTH technician. Online Update: Galaxy G6 supports to update the firmware online anytime if there is something - 56 -...
  • Page 57 Galaxy G6 update or optimized. Local Update: Update the latest firmware by using a firmware file. How to upgrade the firmware with Local Update Click on Browse button to load firmware file (Please take in mind that the firmware is ended with .img as the extension name).

  • Page 58: User Management

    , then the receiver will restart automatically. SPECIAL REMIND: Galaxy G6 doesn t support to update the firmware with the help of INstar program any more, in the future, update the firmware for Galaxy G6 shall be done through the Web UI.

  • Page 59: Help

    Galaxy G6 §3.2.10 Help In this page, users can get help and check the log book of receiver (the log book can help to backtrack the working status of receiver). NOTE: Only the administrator can modify any parameters for receiver and manage users, and the ordinary users only have the right to view the relative parameters.

  • Page 60: Chapterⅳ Data Collector S10

    Galaxy G6 ChapterⅣ Data Collector S10 §4.1 Basic introduction to the handheld Here takes S10 for example (If you want to know more about Psion controller, please refer to the manual for Psion controller), appearance of S10: - 60 -...
  • Page 61 Galaxy G6 Standard Configuration Description Li-ion Battery 3.7V/ 3000 mA/h Strap Black, 180*12mm Touch Pen Black, 12.7mm USB data cable 1.5m USB Charger 5V/1A Disc - 61 -...
  • Page 62 Galaxy G6 Charging Connect the charger with collector by the USB Link cable to recharge. Main Screen (Upper right corner) will show the Charging Icon in power off (on) status.(Once you connect Collector with PC to recharge; the charging time will be longer).
  • Page 63 Galaxy G6 Installing Program Make sure that collector is synchronized with PC. Run the Installation file at PC side. If the installation program is also suitable for collector, you can copy the installation program into collector to install. You can just copy the folder into collector when you need.

  • Page 64: Bluetooth Connection

    Galaxy G6 Press Camera Key to take a photo and click OK on the screen to save. Note: If you want to know more information about S10, Please refer to S10 manual. §4.2 Bluetooth Connection The short-range wireless Bluetooth communication facilities are for the wireless exchange of information among a variety of Bluetooth-enabled devices.

  • Page 65: Software Installation And Connecting

    Galaxy G6 After the pair, select an available com port for the receiver (usually COM 8 and COM 5 are OK). As shown below: After the establishment of the virtual serial port, other applications can use the serial port for data communication with a Bluetooth device.
  • Page 66 Galaxy G6 takes EGStar for example: EGStar is the specific software for G1 measuring system, mainly for the collection and calculation of the measuring points. Before installing of EGStar, you need to install Microsoft Active Sync. After installing it on your...
  • Page 67 Galaxy G6 2. Or go to Bluetooth Manager , in this interface tap on Search button and the controller will search the surrounding Bluetooth devices, select the correct serial number from the list and click on Connect button, controller will connect to receiver without setting any COM port. If the...

  • Page 68: Chapterⅴ External Radio

    Galaxy G6 ChapterⅤ External Radio §5.1 Overview The radio GDL20 is a high-speed semi-manual wireless data transmission radio, whose air transfer rate can be up to 19200 bps and the RF transmitter power is larger, used in Southern RTK measurement system.

  • Page 69: Radio Appearance

    Galaxy G6 §5.3 Radio Appearance ① Control panel ②SN number Control Panel Control panel lights display the status of the radio, the key operation is simple and convenient, one-to-one interface can effectively prevent connection errors. ① Channel indicator light. ② Power indicator light, ③...

  • Page 70: Radio Interfaces

    Galaxy G6 §5.4 Radio Interfaces Mainframe Interface: 5-pin jack for connecting a GPS receiver and power supply Antenna interface For connecting the transmitter antenna Power switch (Shown in picture below): switch to adjust the radio power, AMP PWR lights on the panel indicate the radio power level, light on indicates low power, lights off high power.
  • Page 71 Galaxy G6 data link unstable or unable to launch. GDL20 radio power supply: voltage 12-15V (typical 13.8V) RF transmitter power 25W, current 7.0A. Radio transmits power: radio transmits power based on the voltage of the power supply, check the voltage before use.

  • Page 72: Chapterⅵ Accessories

    ChapterⅥ Accessories §6.1 Instrument Case The instrument case for Galaxy G6 contains two layers of packing: the inner layer is filled with anti-collision foam, the host and other accessories can be dispersed and embedded; the outer layer is a hard instrument case, sealing-strong, wear-resistant anti-wrestling. Compact, durable, can effectively prevent the impact, easy to clean §6.2 Batteries &...
  • Page 73 Galaxy G6 Charger ① ② ④ ③ ① adapter connection cable ② adapter ③ charger ④ charging indicators (FULL/CHARGE) - 73 -...

  • Page 74: Portable Power Package

    NOTE: If CHARGE indicator glows in red, it indicates the battery is being charged, If FULL indicator glows in green, it indicates the battery is full charged. §6.2.2 Portable power package Galaxy G6 is equipped with a professional battery package that ensures a long time continuous work. - 74 -...

  • Page 75: Differential Antennas

    Galaxy G6 ① ② ④ ③ ⑤ ① Indicators, the indicators indicates how much power remain by pressing the power button. ② The combination batteries installed into the portable power source ③ Hang buckle, hang the battery package onto tripod ④...

  • Page 76: Cables

    Galaxy G6 UHF Antenna UHF Antenna GPRS Antenna GPRS Antenna The differential antennas are as shown above; The UHF differential antenna is required to install to the interface at the top of receiver if Galaxy G6 is set up into internal UHF mode.

  • Page 77: Other Accessories

    7-pin end, connect to receiver 7-pin to OTG cable This cable is used to connect an external storage directly to Galaxy G6 for static data storage and copy. USB interface Communication cable This cable is used to connect the receiver to computer for receiver debugging, differential data checking and firmware update.
  • Page 78 Galaxy G6 Tribrach & connector Measuring tape Support pole Bracket for controllers Carbon fiber pole NOTE: The models and types of instrument accessories will vary with the instrument upgrade. - 78 -...

  • Page 79: Chapter Ⅶ Measuring Operation

    Galaxy G6 Chapter Ⅶ Measuring Operation Reading this chapter, you can grasp in detail how to use the G1 measurement to do system static, RTK operations. GPS measurement operation scheme refers to the operating scheme used to determine the relative position between the stations with the help of GPS technology. Point coordinate precision obtained is not the same;...

  • Page 80: Operating Procedures

    Galaxy G6 The establishment of precision engineering control network, such as bridge measurement, tunnel measurements, etc; The establishment of a variety of encryption control network, such as city measurements, Drawing Point measurement, road surveying, demarcation measurements. For the GPS measurements of small and medium-sized cities, towns, as well as mapping,...

  • Page 81: Gps Net Design

    Galaxy G6 5)Power on, confirm the static mode, the mainframe begins to search satellites and satellite lights begin to flash. Recording condition reached, the status light flashes in accordance with the set sampling interval, flashing once indicates the acquisition of an epoch.

  • Page 82: Antenna Height Measurement

    Galaxy G6 and consistency. General speaking, the amount of baselines has such limit as follows: The advantage of circle net is the small workload, good self-checking and consistency. But the main disadvantage is that the accuracy of indirect-observed border is lower than that of direct-observed border, and the baseline accuracy of neighbor points distributes unevenly.
  • Page 83 Galaxy G6 Measuring plate We use a formula to calculate antenna height. h is the inclined height that measure from point on the ground to the measuring plate edge. is the distance from middle of antenna to the edge of measuring plate.

  • Page 84: Rtk Measurement

    Galaxy G6 §7.2 RTK measurement RTK is the abbreviation of Real-Time Kinematic measurements. RTK technology is the real-time dynamic differential carrier phase positioning technology, combining global satellite navigation and positioning technology with data communication technology which includes base station and rover station. Base station transmits the data by radio or network to the rover station, which will perform differential analysis, thus providing real-time coordinates of the measurement point in the specified coordinate system.
  • Page 85 Tap on Work mode setting and then check the box of Set work mode , then click on Next to continue; Check the box of Base option and click OK and return to Instrument setting page. At this moment, Galaxy G6 prompts the correct working mode with voice guide. - 85 -...
  • Page 86 Galaxy G6 Then tap on Work mode setting and then check the box of Set data link , then click on Next to continue; Check the box of Internal radio option and click OK to complete the settings. Return to the main interface and again get into instrument config page, tap on Base setting to get into Base configuration page.
  • Page 87 Galaxy G6 10) Input the coordinates for base location or tap on the symbol to obtain a single position for base. 11) After all the parameters are completel set, click on Start button to start the base station. REMIND: If the base station is still set up on the same position next time, check the bo of repeated station option and the base station ill start automatically with known coordinates.
  • Page 88 Galaxy G6 Using internal Web UI Connect Galaxy G6 with computer via 7-pin to USB cable and set the USB port to output as Ethernet on G6. (a driver is required to installed on computer to enable this function). Login the internal Web UI of G6 with the default username and password (admin/admin).
  • Page 89 Galaxy G6 Get into Radio Parameters interface under Radio Config , configure the radio parameters for base station such air baud rate, channel value, power and protocol. - 89 -...
  • Page 90 Galaxy G6 §7.2.1.3 Rover station set up After verifying the successful transmitting of the Base station, the rover station shall be set up at this moment. Install the bracket holder onto the carbon fiber pole, and fix the controller into the bracket, then power on the controller.
  • Page 91 Galaxy G6 Rover receiver UHF receiving antenna GPRS receiving antenna Carbon fiber pole Bracket Data collector - 91 -...
  • Page 92 Tap on Work mode setting and then check the box of Set work mode , then click on Next to continue; Check the box of Rover option and click OK and return to Instrument setting page. At this moment, Galaxy G6 prompts the correct working mode with voice guide. - 92 -...
  • Page 93 Galaxy G6 Then tap on Work mode setting and then check the box of Set data link , then click on Next to continue; Check the box of Internal radio option and click OK to complete the settings. Radio channels setting Go to Config Device Config Radio Config page.
  • Page 94 Galaxy G6 Using Web UI Connect Galaxy G6 with computer via 7-pin to USB cable and set the USB port to output as Ethernet on G6. (a driver is required to installed on computer to enable this function). Login the internal Web UI of G6 with the default username and password (admin/admin).

  • Page 95: By Using Radio (External Radio)

    Galaxy G6 §7.2.2 By using radio (external radio) §7.2.2.1 Base station setup Set a tripod to the location with known coordinates (or unknown), attach base receiver to the tribrach adapter set (the measuring plate is recommended to install under base receiver).
  • Page 96 Galaxy G6 At least 2m away NOTE: place the 2 tripods at least 2m away from each other against signal interference. Using EGStar3.0 Set the base receiver as base working mode from Config Device Config Instrument Config Work mode setting Set work mode--Base , choose the External option in Set data link .

  • Page 97: By Using Internet (Gprs)

    Galaxy G6 §7.2.2.2 Radio settings Make sure all connections are alright, then power on the radio by pressing power button, and then press C button to define the channel for data transmission. Please keep in mind the channel is selected to match the settings in controller later on.
  • Page 98 Galaxy G6 Input a name for NTRIP connection and choose NTRIP-VRS for Mode and choose GPRS/CDMA for Connect. Then click on Change button to define the ANP for our local SIM card. - 98 -...
  • Page 99 Galaxy G6 Input the IP address and port, then input the assigned username and password for your NTRIP connection. Press Get Sourcetable button to obtain mountpoint list, then select the appropriate one from the list in Access option, press OK button to confirm and return to Network Setting interface.
  • Page 100 Galaxy G6 NOTE; the parameters would be automatically saved up once input, the receiver would track the CORS info most recently input and connect when it gets started next time. Web UI settings Login the web UI of G6 and go to General Config interface, then choose Network in Datalink option, click on Enter button to confirm and save the settings.
  • Page 101 Galaxy G6 Go to NTRIP Config interface under Data Transfer , and input the CORS server information including IP, Port, User and password, then click Get Point button to download mountpoint list from server. Then select the appropriate one from the list and click on Enter button at the bottom to access.

  • Page 102: By Using Internet (Wifi)

    Galaxy G6 §7.2.4 By using internet (WIFI) WiFi datalink is a new feature and new technology adopted on Galaxy G6, it is more faster and stable in network RTK job. Set the receiver as rover with WIFI mode on the control panel or on Web UI.
  • Page 103 Galaxy G6 Web UI settings Login the web UI of G6 and go to General Config interface, then choose WIFI in Datalink option, click on Enter button to confirm and save the settings. Then go to WIFI Config interface under Network Config , there the option of Client is activated if WIFI used as datalink.
  • Page 104 Galaxy G6 If the WIFI connection is successfull connected, go to NTRIP Config interface under Data Transfer , and input the CORS server information including IP, Port, User and password, then click Get Point button to download mountpoint list from server. Then select the appropriate one from the list and click on Enter button at the bottom to access.

  • Page 105: Tilt Survey

    Galaxy G6 §7.2.5 Tilt Survey Electronic Bubble Start electronic bubble In the main interface, click the calibration setting button on the top of the interface, then get into the setting interface. Mark on the checkbox of Bubble option in the setting interface, click OK return to Point survey interface, there appears the electronic bubble on the upper left of the screen.
  • Page 106 Galaxy G6 Sensors Calibration Galaxy G6 supports tilt survey function, but before doing the tilt surveying on Galaxy G6, the sensors calibration shall be done. 1. Electronic Bubble calibration Get into calibration interface by clicking on calibration setting button on the top of the screen.
  • Page 107 Galaxy G6 2 Magnetic calibration In the calibration setting interface, click Magnetic to enter the magnetic calibration interface. In the megnetic calibration interface, click Start to start the calibration, then flip and rotate the G6 according to the sketch map on the left bottom of the screen ( ou can also draw after G6 is connected to the carbon fiber pole), until the calibration is finished 100%.

  • Page 108: Radio Router

    Galaxy G6 Tilt Surveying After finishing the calibration for sensors, you can start tilt survey with Galaxy G6 in the tough conditions such as under the eave or around the wall, this function can correct the slant coordinates to the normal coordinates within 30° angle of inclination.

  • Page 109: Appendix A Galaxy G6 Technical Specifications

    Galaxy G6 Appendix A Galaxy G6 technical specifications Signals Tracked Simultaneously Channels 220 Channels B1, B2, B3 L1C/A, L1C, L2C, L2E, L5 GLONASS L1C/A, L1P, L2C/A, L2P, L3 SBAS L1C/A, L5 (Just for the satellites supporting L5) GALILEO GIOVE-A, GIOVE-B, E1, E5A, E5B...
  • Page 110 Integrated internal radio receiver and transmitter, 0.5W/2W/3W optional Wireless Modem External radio transmitter 5W/25W Frequency Range 410-470MHz Communication Protocol TrimTalk450s, TrimMark3, PCC EOT, SOUTH WCDMA3.5G network communication module, downward compatible Cellular Mobile Network with GPRS/EDGE customized CDMA2000/EVDO 3G and TDD-LTE/FDD-LTE 4G module Double Module Bluetooth BLEBluetooth 4.0 standard, support for android, ios cellphone connection...

  • Page 111: Appendix B Gdl-20 Radio Technical Specifications

    Galaxy G6 Support external USB storage The customizable sample internal is up to 50Hz Plug and play mode of USB data transmission Data Transmission Support FTP/HTTP data download Differential data format: CMR+, CMRx, RTCM 2.1, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2...
  • Page 112 Galaxy G6 Antenna impedance Ambient temperature -25°C 60°C Humidity 10-90% relative humidity, non-condensing Receiver Specifications 0.25 V(12dB SINAD) Receiver sensitivity 65dB Adjacent Channel Selectivity Modulation signal frequency 5.1KH deviation Intermodulation Rejection 65dB Ratio Audio distortion Transmitter indicators RF output power...

  • Page 113: Appendix C Technical Terms

    Galaxy G6 Appendix C Technical Terms Ambiguity: unknown quantity is the integer number of cycles of the carrier phase measured from the satellite to the receiver. Baseline: The connection line of the two measurement points, on which to receive GPS signals and collect observation data simultaneously.
  • Page 114 Galaxy G6 Multipath error: the positioning error caused by the interference between two or more radio signal propagation path. Observing session: the use of two or more receivers at the same time to collect GPS data period. Pseudo Range: GPS receiver in the time required to copy the code aligned with the received GPS code offset and multiplied by the speed of light to calculate the distance.
