Elmdene G240 N Series Manual

27.6V S M
DC WITCH ODE
W R F S
ITH EMOTE AULT IGNALLING
F
EATURES
High efficiency cost effective power supply ideal for use in Fire, Access Control and General Security
applications. Featuring a regulated 27.6Vdc output supplying continuous full rated current to load and up to
an additional 0.5A for charging 2 x 12V standby batteries, if fitted. The universal mains input voltage enables
the power supply to be used across a wide geographical area. The highly efficient switch mode design ensures
low operating costs, generates less heat and with a small physical size increases the room available for
additional PCBs or cables. The modular construction simplifies maintenance.
Continuous full rated current to load
Additional 0.5A to charge 2 x 12V standby
batteries
Universal mains input voltage 90-264Vac
High efficiency electronics for reduced running
costs and lower operating temperatures
Installer safe design with all high voltage
electronics fully shrouded
Reverse battery connection protection
S
PECIFICATION
Input Specification
Voltage (rated)
Voltage (operating)
Frequency
Max Current
Mains Input Fuse
Max standby Power
Output Specification
Voltage
Max load current
Ripple
Load output Fuse
Overload
www.acornfiresecurity.com
P S
OWER UPPLIES
100-240Vac
90-264Vac
50-60Hz
See Model Specification Table
See Model Specification Table
0.8W (No load and no battery connected)
27.0 – 28.0Vdc (27.6Vdc nominal) on mains power
21.0 – 24.7Vdc on battery standby
See Model Specification Table
100 mV pk-pk max
See Model Specification Table below
Electronic shutdown until overload or short circuit removed
(under mains power only) (G2403N & G2405N)
Fuse Protection (G2401N & G2402N)
www.acornfiresecurity.com
Models:
G240xN-y
Where 'x' is max load current and 'y' is Enclosure type
Modular construction for ease of maintenance
and installation
Full electronic short circuit and overload
protection on load output under mains
operation
Mains transient protection circuit
Green Mains present LED
Yellow Fault LED
