Elmdene GEN2-08 Series Instruction Sheet

Elmdene International Ltd
3 Keel Close, Interchange Park,
Portsmouth, Hampshire, PO3 5QD, UK
13.8Vdc Switch Mode Power Supply
#
GEN2-08-y
#
GEN2-18-y
for 18Ah Battery and up to 1.5A* Continuous Load Current
F
EATURES
High efficiency cost effective power supply suitable for use in systems designed to comply with
PD6662:2010 and EN50131-6:2008 Grade 2 and Environmental Class II requiring 8Ah or 18Ah standby
battery capacity. Two independent output signals are provided for loss of mains fault (EPS**), and
general fault (including APS** fault). Self-diagnostics can detect blown output and battery fuses and
low battery voltage (APS fault). The PSU incorporates a battery management system comprising low
battery voltage detection and deep discharge protection to ensure that the battery is not permanently
damaged through excessive discharge. A brownout filter ensures that short mains voltage dips do not
create a false loss of mains alarm. Two LEDs assist with quick and easy installation by showing
presence of mains, correct battery charging and a fault condition. Comprehensive protection is built-in
as standard including mains transient filtering, electronic output overload protection and fuses on the
load and battery outputs.
PD6662:2010 and EN50131-6:2008
•
Type A, Security Grade 2
Environmental Class II Compliant
Low quiescent battery monitoring current during standby operation
•
Fault signals for loss of mains, power supply fault, and battery low voltage warning
•
Battery Deep Discharge Protection
•
Protection against reverse battery connection
•
LED for comprehensive diagnostics
•
Thermal protection of power circuitry
•
Mains transient suppression and brown-out filter
•
Fully enclosed lid tamper circuit
•
#
"y" Denotes enclosure size – see overleaf
* See table overleaf to determine continuous standby battery current available for given standby times
** EN50131 Definitions:
Technical Support: +44(0)23 9269 6638 (option 3)
for 8Ah Battery and up to 1.0A* Continuous Load Current
EPS = External Power Source
Tel: +44(0)23 9269 6638
Fax: +44(0)23 9266 0483
Web:
APS = Alternative Power Source
PAK200545_03B May 2016
www.elmdene.co.uk
©2016 ELMDENE INTERNATIONAL LTD
1
