Elmdene G1380xBM Series Manual

Elmdene International Ltd
3 Keel Close, Interchange Park,
Portsmouth, Hampshire, PO3 5QD, UK
13.8V S
DC WITCH
W B M
ITH ATTERY ONITORING AND
F
EATURES
High efficiency cost effective power supply range ideal for use in Intruder, Access Control and General
Security applications. Featuring a regulated 13.8V dc output supplying continuous full rated current to load
and a universal mains voltage input. Maximum battery life is assured using deep discharge protection to
prevent premature battery failure when operating in standby mode for extended periods. Two sets of volt
free contacts are provided to signal (i) loss of mains and (ii) battery and loss of output faults.
Continuous full rated current to load
•
Universal mains input voltage 90-264V ac
•
High efficiency electronics for reduced
•
running costs and lower operating
temperatures
Installer safe design with all high voltage
•
electronics fully shrouded
Mains transient protection circuit
•
Lid and removal from wall tamper detection
•
Green Mains present LED
•
S
PECIFICATION
Input Specification
Voltage (rated)
Voltage (operating)
Frequency
Max Current
Mains Input Fuse
Output Specification
Voltage
Max load current
Ripple
Load output Fuse
Overload
Standby Battery
Battery Type
Battery Capacity
Battery Charging Fuse protection
Technical Support Line +44 (0)23 9269 6638 (Option 3) G1380xBM-y-s
M P S
ODE OWER UPPLIES
R F
EMOTE AULT
100-240V ac
90-264V ac
50-60Hz
See Model Specification Table
See Model Specification Table
12.8 – 14.2V dc (13.8V dc nominal) on mains power
9.8 – 13.0V dc on battery standby
See Model Specification Table
< 400 mV pk-pk max
See Model Specification Table below
Electronic shutdown until overload or short circuit removed (under mains
power only)
Models:
G1380xBM-n-y / G1380xBMU
S
IGNALLING
Where 'x' is max load current: 1A or 2A, 'n' is number of
fused outputs, and 'y' is Enclosure type A, B, C, D or R
Available in unboxed (module only) format
•
Red Fault diagnostic LED
•
Volt free contact signalling mains failure (EPS)
•
Volt free contact signalling output and battery
•
faults (GEN)
Full electronic short circuit and overload
•
protection on load output under mains
operation
Individual battery and output fuse protection
•
12V Valve Regulated Lead Acid
See below under Mechanical specification.
See Model Specification Table below
PAK200569_01C June 2016
Tel: +44 (0)23 9269 6638
Fax: +44 (0)23 9266 0483
Web: www.elmdene.co.uk
© 2016 Elmdene International Ltd
