Elmdene G240 BM Series Instruction Sheet

Elmdene International Ltd
3 Keel Close, Interchange Park,
Portsmouth, Hampshire, PO3 5QD, UK
27.6V S M
DC WITCH
W R F S
ITH EMOTE AULT IGNALLING AND
F
EATURES
High efficiency cost effective power supply ideal for use in Fire, Access Control and General Security applications.
Featuring a regulated 27.6Vdc output supplying continuous full rated current to load plus additional current for
charging 2 x 12V standby batteries. Maximum battery life is assured using deep discharge protection to prevent
premature battery failure when operating in standby mode for extended periods. Two sets of volt-free contacts are
provided to signal (i) loss of mains and (ii) battery and loss of output faults. The universal mains input voltage enables
the power supply to be used across a wide geographical area. The highly efficient switch mode design ensures low
operating costs, generates less heat and with a small physical size increases the room available for additional PCBs or
cables. The modular construction simplifies maintenance.
• Continuous full rated current to load
• Additional current to charge 2 x 12V standby
batteries
• Battery Deep Discharge Protection
• Universal mains input voltage 90-264Vac
• Volt free contact signalling mains failure
• Volt free contact signalling output and battery faults
• High efficiency electronics for reduced running costs
and lower operating temperatures
• Installer safe design with all high voltage electronics
fully shrouded
S
PECIFICATION
Input Specification
Voltage (rated) / (operating)
Max Current / Input Fuse
Max standby Power
Output Specification
Voltage
Max load current / load fuse
Ripple
Overload
Technical Support Line +44 (0)2392 696638
P S
ODE OWER UPPLIES
B M
ATTERY ONITORING
100-240Vac / 90-264Vac (Both at 50 – 60Hz)
See Model Specification Table
0.8W (No load and no battery connected)
27.0 – 28.0Vdc (27.6Vdc nominal) on mains power
21.0 – 24.7Vdc on battery standby
See Model Specification Table
100 mV pk-pk max
Electronic shutdown until overload or short circuit removed
(under mains power only) (G2403BM & G2405BM)
Fuse Protection (G2401BM & G2402BM)
Tel: +44 (0)23 9269 6638
Fax: +44 (0)23 9266 0483
Web:
Models:
G240xBM-y
Where 'x' is max load current and 'y' is Enclosure type
• Reverse battery connection protection
• Modular construction for ease of maintenance and
installation
• G2403 & G2405 - Full electronic short circuit and
overload protection on load output (under mains power
only)
• G2401 & G2402 - Fuse protection
• Mains transient protection circuit
• Green Mains present LED
• Yellow Fault LED
• Orange Battery Charging LED (visible on PCB only)
G240xBM-x-y PAK200536_01G May 2016
