13.8V dc Switch Mode Power Supply with Optional Fused Outputs
G1380xN-y-s
F
EATURES
High efficiency cost effective power supply ideal for use in Intruder, Access Control and General
Security applications. Featuring a regulated 13.8Vdc output supplying continuous full rated current to
load and up to an additional 0.5A for charging a standby battery. The universal mains input voltage
enables the power supply to be used across a wide geographical area. The highly efficient switch
mode design ensures low operating costs, generates less heat and with a small physical size increases
the room available for additional PCBs or cables. The modular construction simplifies maintenance. An
optional integrated output module allows multiple circuits to be individually fused*.
Continuous full rated current to load
Additional 0.5A to charge standby battery
Universal mains input voltage 90-264Vac
High efficiency electronics for reduced running costs and lower operating temperatures
Installer safe design with all high voltage electronics fully shrouded
Modular construction for ease of maintenance and installation
Full electronic short circuit and overload protection on load output under mains operation
Mains transient protection circuit
Lid opening tamper detection
Green Mains present LED
Red Fault LED*
Individually Fused Outputs*
* Dependent upon model.
C
OMPLIANCE
This power supply unit meets the essential requirements of the following European Directives:
Low Voltage 2014/35/EU
S
(I
PECIFICATION
NPUT
Voltage (rated)
Voltage (operating)
Frequency
Max current
Mains Input Fuse
Max standby Power
Technical Support: +44(0)23 9269 6638 (option 3)
EMC 2014/30/EU
)
100-240Vac
90-264Vac
50-60Hz
See Model Specification Table overleaf
See Model Specification Table overleaf
0.5W (No load and No battery connected)
PAK200500_03C Dec 2016
Tel: +44(0)23 9269 6638
Fax: +44(0)23 9266 0483
Web:
www.elmdene.co.uk
WEEE 2012/19/EU
©2016 ELMDENE INTERNATIONAL LTD
RoHs2 2011/65/EC
1
